Schneider270 (FCP270) - Field Control Processor

System scalability by interconnecting Ethernet switches, each having 8-ports or more in various increments  Support for Fast Ethernet (100 Mbps) and Gigabit (uplink only) Ethernet (1000 Mbps)  Modular uplinks to high-speed backbones using 1 Gb 1000Base-T, 1000Base-SX, 1000Base-LX, 1000Base-LX/LH, 1000Base-BX, 1000Base-TX, and 1000Base-ZX standards  Full duplex operation based on the IEEE 802.3 standards

The 24-Port Copper managed switch (P0973JM) provides twenty-four 100Base-TX ports with RJ-45 connectors, two fixed 10/100/1000 stacking / uplink (ISL) ports and two 1000Base-X uplink (ISL) Gigabit (SFP) ports. The two 1000Base-X uplink (ISL) Gigabit (SFP) ports can be populated with MGBIC uplink (ISL) connector modules listed in Table 3. The switch allows high-performance, full-featured layer-2 Ethernet switching in small to medium-sized network applications, as well as high-performance direct end-station connectivity. FEATURES The 24-Port Copper managed switch features:  24-ports of 100Base-TX  Two fixed RJ-45 10/100/1000 ports, configurable for uplink  Two 1000Base-X uplink Gigabit (SFP) ports  Full duplex operation  Supports VLAN configurations  Monitoring and configuration tasks via local console port, or any SNMP/RMON based management application.  Port mirroring technology and diagnostics that allow local network traffic to be redirected to an external probe for detailed analysis  Compliance with industry standards, including IEEE 802.3u Fast Ethernet, 802.1w Rapid Spanning Tree Protocol (RSTP)  Optional redundant power supply  Shelf, desk, or 19-inch rack mounting. OPTIONAL REDUNDANT POWER SUPPLY See “REDUNDANT POWER SUPPLY (P0973BP)” on page 27.

The main points to note regarding Schneider270 (FCP270) include the following: Installation environment and environmental conditions: FCP270 can operate in G3 harsh environments and has passed CE certification. It can be installed on-site in a cabinet without the need for special protective equipment. Ventilation requirements: Due to its efficient design, the FCP270 does not require ventilation. Power supply and electrical connection: Ensure that the power supply meets the equipment requirements to avoid equipment failure caused by power supply issues. Electrical connection: The backplane provides a modular design for the PLC, establishing electrical connections between independent components, including power supply and communication signals. Many PLC manufacturers use proprietary communication protocols on the backplane to ensure secure communication between I/O and CPU. Communication and Network communication protocol: FCP270 supports 2Mbps or 268Kbps HDLC fieldbus, and simultaneously supports communication for 100 series and 200 series FBMS. Network connection: Connect to the MESH control network via standard fiber optic 100Mbps Ethernet to achieve remote installation and distributed control. Fault Tolerance and Reliability Fault Tolerance operation: FCP270 offers a unique patented fault tolerance operation, consisting of two parallel running modules, ensuring continuous operation even in the event of hardware failure. Online update: Supports online image update, allowing for the replacement of executable images without closing the process. Maintenance and upgrade spare parts management: Ensure there is an adequate inventory of spare parts, such as FBM modules, etc., to deal with sudden failures. Upgrade options: There are multiple upgrade options available to replace the control processor and enhance system performance by 12. Time and Synchronization Time synchronization: Supports the use of external time from GPS satellites for time synchronization to ensure system time accuracy. Other precautions: Programming and configuration: Use appropriate programming devices and HMI for system configuration and monitoring. 5. Safety protection: Ensure that safety protection measures are in place during the installation and operation of the equipment to prevent accidental damage. By following these precautions, the stable operation and long-term reliability of the FCP270 can be ensured.
