GEInstallation and Maintenance Manual Bently Nevada™ Asset Condition Monitoring

Figure 2-3: 3500 Rack (Full-Size)

The following sections list the function of each module. Refer to the individual

operation and maintenance manuals for available options, detailed description,

operation and maintenance.

2.3.1 Weatherproof Housing

The weatherproof housing protects the 3500 rack from adverse environmental

effects, such as excessive moisture, dirt and grime, and even unclean air. The

weatherproof housing will not accommodate a Display Unit or VGA Display.

2.3.2 Rack

2 types of 3500 racks are available: the full-size 19-inch rack and the compact 12-

inch Mini-rack. Each rack requires you to install the Power Supplies and Rack

Interface Module (RIM) in specific locations. The full-size version offers 14

additional rack positions and the Mini-rack offers 7 additional rack positions. You

may use these positions to install any combination of modules. Both racks

support Standard (non-redundant) and Triple Modular Redundant (TMR)

configurations

Application Advisory

The TMR system will restrict the

location of certain modules.

2.3.3 Power Supply

The Power Supply is a half-height module available in ac and dc versions. You

can install 1 or 2 power supplies in the rack. Each power supply can power a fully

loaded rack. When you install 2 power supplies in a rack, the supply in the lower

slot acts as the primary supply and the supply in the upper slot acts as the

backup supply. If the primary supply fails, the backup supply will provide power to

the rack without interrupting rack operation. The 3500 design allows you to

install any combination of power supply types.

Overspeed Detection and TMR Monitors require dual power supplies.

2.3.4 Rack Interface Module

The Rack Interface Module (RIM) is a full-height module that communicates with

the host (computer), a Bently Nevada™ Communication Processor, and the other

modules in the rack. The Rack Interface Module also maintains the System Event

List and the Alarm Event List. You can daisy-chain this module to the Rack

Interface Modules in other racks and to the Data Acquisition / DDE Server

Software. The 3500 Monitoring System Computer Hardware and Software Manual

shows how to daisy chain the Rack Interface Modules together. Rack Interface

Modules are available in Standard, Triple Modular Redundant and Transient Data

Interface versions.

2.3.5 Communication Gateway Module

The Communication Gateway Module is a full-height module that allows external

devices (such as a DCS or a PLC) to retrieve information from the rack and to set

up portions of the rack configuration. You can install more than one

Communication Gateway Module in the same rack. Communication Gateway

Modules are available for a variety of network protocols.

2.3.6 Monitor Module

The Monitor Modules are full-height modules that collect data from a variety of

transducers. You can install any combination of Monitor Modules in the 3500

rack.

2.3.7 Relay Module

Relay Modules provide relays that you can configure to close or open based on

channel statuses from other monitors in the 3500 rack. Relay modules are

available in 4-channel, 16-channel, and 4-channel Triple Modular Redundant

(TMR) versions.

The TMR Relay Module is a half-height 4-channel module that operates in a TMR

system. 2 half-height TMR Relay Modules must operate in the same slot. If you

remove the upper or lower Relay Module or the system declares one of the

modules as Not OK, then the other Relay Module will control the Relay I/O Module.

2.3.8 Keyphasor® Module

The Keyphasor Module is a half-height module that provides power for the

Keyphasor transducers, conditions the Keyphasor signals, and sends the signals

to the other modules in the rack. The Keyphasor Module also calculates the rpm

values sent to the host (computer) and external devices (DCS or PLC) and provides

buffered Keyphasor outputs. Each Keyphasor Module supports 2 channels. You

may place up to 2 Keyphasor Modules in a 3500 rack for a maximum of 4

Keyphasor channels. If you use 2 Keyphasor Modules, you must place them in the

same full-height slot and the modules will share a common I/O module.

2.3.9 Display Module

The 3500 system offers multiple display options.

The Display Interface Module can display rack data on an LCD-based Interface

unit or a 3rd-party Modbus® based display unit.

The VGA Display Module will display rack data on certain touch screen VGA

Displays.

The Integrated PC display is a complete rack mount touch screen PC pre-loaded

with rack configuration software and display utilities.

2.3.10 Earthing Module

The Earthing Module is a full-height module that provides a low resistance

connection (must be less than 1 Ω) from the 3500 rack to the plant’s intrinsically

safe earth ground. The module operates in conjunction with the 3500 internal
