ABBAC 800M Controller Hardware Product Guide

NOTICE

This document contains information about one or more ABB products and may include a

description of or a reference to one or more standards that may be generally relevant to

the ABB products. The presence of any such description of a standard or reference to a

standard is not a representation that all of the ABB products referenced in this document

support all of the features of the described or referenced standard. In order to determine

the specific features supported by a particular ABB product, the reader should consult the

product specifications for the particular ABB product.

ABB may have one or more patents or pending patent applications protecting the intellectual property in the ABB products described in this document.

The information in this document is subject to change without notice and should not be

construed as a commitment by ABB. ABB assumes no responsibility for any errors that

may appear in this document.

In no event shall ABB be liable for direct, indirect, special, incidental or consequential

damages of any nature or kind arising from the use of this document, nor shall ABB be

liable for incidental or consequential damages arising from use of any software or hardware described in this document.

This document and parts thereof must not be reproduced or copied without written permission from ABB, and the contents thereof must not be imparted to a third party nor used

for any unauthorized purpose.

The software or hardware described in this document is furnished under a license and

may be used, copied, or disclosed only in accordance with the terms of such license. This

product meets the requirements specified in EMC Directive 2004/108/EC and in Low Voltage Directive 2006/95/EC.

TRADEMARKS

All rights to copyrights, registered trademarks, and trademarks reside with their respective owners.

Copyright © 2003-2013 by ABB.

All rights reserved.

Release: February 2013

Document number: 3BSE036352-510 A

Electrostatic Sensitive Device

Devices labeled with this symbol require special handling precautions as

described in the installation section.

GENERAL

 WARNINGS

Equipment Environment

All components, whether in transportation, operation or storage, must be

in a noncorrosive environment.

Electrical Shock Hazard During Maintenance

Disconnect power or take precautions to insure that contact with energized parts is avoided when servicing.

SPECIFIC

WARNINGS

-50, -63 and Page 70: It is not allowed to manipulate CEX bus base plates

in a powered and running system. Before changing or removing a base

plate, all CEX modules on that segment must be removed.

Page 177: Explosion hazard - Substitution of components may impair

suitability for Class I, Zone 2.

Page 177: Explosion hazard - Do not replace batteries unless the power

has been switched off or the area is known to be non-hazardous.

Page 178: Explosion hazard - Do not disconnect equipment unless the

power has been switched off or the area is known to be non-hazardous.

SPECIFIC

 CAUTIONS

Page 13: This Product guide does not contain last-minute product information and updates which might affect functionality and/or performance.

For information on late changes and restrictions, please refer to the

Release Notes, Control Software for AC 800M (3BSE021377*).

Page 54: Always check that the CPU and other hardware units have the

correct firmware version, before installing them. If the CPU is empty, CPU

firmware must be loaded via the COM4 port.

SPECIFIC

 CAUTIONS

(continued)

Page 175: If you use other power supplies, except SD82X and SD83X, to

provide the 24V d.c. for AC 800M it is required that they also are CE

marked, UL listed and fulfill the LVD (SELVand PELV).

Page 176: The AC 800M modules are to be considered as open equipment, according to EN 61131-2 and UL508, and must be mounted in

non-public localities.

General

This Product Guide is primarily intended for sales representative within ABB.

An additional user group may be internal ABB customers and important external

customers, using the Product Guide as a complement to existing product

information.

Document Conventions

Microsoft Windows conventions are normally used for the standard presentation of

material when entering text, key sequences, prompts, messages, menu items, screen

elements, etc.

Warning, Caution, Information, and Tip Icons

This publication includes Warning, Caution, and Information where appropriate

to point out safety related or other important information. It also includes Tip to

point out useful hints to the reader. The corresponding symbols should be

interpreted as follows:

This Product guide does not contain last-minute product information and updates

which might affect functionality and/or performance. For information on late

changes and restrictions, please refer to the Release Notes, Control Software for

AC 800M (3BSE021377*).

Electrical warning icon indicates the presence of a hazard which could result in

electrical shock.

Warning icon indicates the presence of a hazard which could result in personal
