CTI 2500 Series® Programmable Controllers

From:CTI | Author:LIAO | Time :2025-08-15 | 12 Browse: | Share:

Most CTI and Siemens special function modules are supported. A complete list showing the

compatibility status by module part number is maintained in the Technical Advisory which can be found here:

http://www.controltechnology.com/Files/Products/technical-advisory-(restricted)/2500-Cxxx-technical-advisory1

Ethernet Support

All 2500 Series® Processor models include a built-in Ethernet port which is compatible with the ports on the CTI 2572

and 2572-A Ethernet Adapters. The capabilities of the Ethernet port on the processor differs slightly from those of the

ports on the Ethernet Adapters. The table below summarizes the features included on each product

Port 4452: One TCP connection for programming software. This port receives priority in communications.

Ports 1505 or 4450: Three TCP connections for data access.

2500-Cxxx Programmable Controllers Model Comparison
