Sieger System 57

System 57 - the heart of fire and gas control.

For almost half a century, Sieger gas detection systems have provided the safety needed to protect plant and personnel from flammable and toxic gas hazards.

Across the globe, they are installed in a wide variety of applications ranging from simple small scale systems to some of the world's largest fully integrated fire and gas detection systems.

To fulfil the unique requirements of each individual application requires a control system with unlimited flexibility.

 The modular design approach employed by the Sieger System 57 enables you to define, in detail, the unique control and alarm parameters to fulfil your requirement.

System 57 accepts inputs from flammable and toxic gas detectors, a large range of flame, smoke and heat detectors and manual call points.

Available outputs include relays, analog signals and industry standard digital protocols.

Packaged in either wall mounting cabinets or panel mounting racks, System 57 can be used stand alone or integrated into the heart of a fire and gas system.

Whatever the application, large or small, our sales engineers and customer service representatives are available to discuss your requirements and recommend the control system that's best for you.

A world of control technology

High precision, intelligent control

Master/voted alarm options

High packing density

Flexible I/O configuration

Relay output options

Part Numbers

Single Channel Control Card + Interface card (for front access racks)

05701-N-6100 5701 Catalytic, Field Interface, Interconnect cable

05701-N-6101 5701 Catalytic, Double SPCO, Interconnect cable

05701-N-6102 5701 Catalytic, Triple SPCO, Interconnect cable

05701-N-6103 5701 Catalytic, Triple DPCO, Interconnect cable

05701-N-6104 5701 Catalytic, High Integrity Relay, Interconnect cable

05701-N-6105 5701 mA, Field Interface, Interconnect cable

05701-N-6106 5701 mA, Double SPCO, Interconnect cable

05701-N-6107 5701 mA, Triple SPCO, Interconnect cable

05701-N-6108 5701 mA, Triple DPCO, Interconnect cable

05701-N-6109 5701 mA, High Integrity Relay, Interconnect cable

Single Channel Control Card + Interface Card + Analogue Output (for front access racks)

05701-N-6110 5701 Catalytic, Analogue output, Field Interface, Interconnect cable

05701-N-6111 5701 Catalytic, Analogue output, Double SPCO, Interconnect cable

05701-N-6112 5701 Catalytic, Analogue output, Triple SPCO, Interconnect cable

05701-N-6113 5701 Catalytic, Analogue output, Triple DPCO, Interconnect cable

05701-N-6114 5701 Catalytic, Analogue output, High Integrity Relay, Interconnect cable

05701-N-6115 5701 mA, Analogue output, Field Interface, Interconnect cable

05701-N-6116 5701 mA, Analogue output, Double SPCO, Interconnect cable

05701-N-6117 5701 mA, Analogue output, Triple SPCO, Interconnect cable

05701-N-6118 5701 mA, Analogue output, Triple DPCO, Interconnect cable

05701-N-6119 5701 mA, Analogue output, High Integrity Relay, Interconnect cable

Single Channel Control Card + Interface card (for rear access racks)

05701-N-6200 5701 Catalytic, Field Interface

05701-N-6201 5701 Catalytic, Double SPCO

05701-N-6202 5701 Catalytic, Triple SPCO

05701-N-6203 5701 Catalytic, Triple DPCO

05701-N-6204 5701 Catalytic, High Integrity Relay

05701-N-6205 5701 mA, Field Interface

05701-N-6206 5701 mA, Double SPCO

05701-N-6207 5701 mA, Triple SPCO

05701-N-6208 5701 mA, Triple DPCO

05701-N-6209 5701 mA, High Integrity Relay

Single Channel Control Card + Interface Card + Analogue Output (for rear access racks)

05701-N-6210 5701 Catalytic, Analogue output, Field Interface

05701-N-6211 5701 Catalytic, Analogue output, Double SPCO

05701-N-6212 5701 Catalytic, Analogue output, Triple SPCO

05701-N-6213 5701 Catalytic, Analogue output, Triple DPCO

05701-N-6214 5701 Catalytic, Analogue output, High Integrity Relay

05701-N-6215 5701 mA, Analogue output, Field Interface

05701-N-6216 5701 mA, Analogue output, Double SPCO

05701-N-6217 5701 mA, Analogue output, Triple SPCO

05701-N-6218 5701 mA, Analogue output, Triple DPCO

05701-N-6219 5701 mA, Analogue output, High Integrity Relay

Four Channel Control Card + Interface Card (for front access racks)

05704-N-0101 5704 Catalytic, Quad Relay, Interface Interconnect Cable

05704-N-0102 5704 Catalytic, Relay Interface Assembly, Interconnect Cable

05704-N-0103 5704 mA, Quad Relay Interface, Interconnect Cable

05704-N-0104 5704 mA, Relay Interface Assembly, Interconnect Cable

Note: * = Must order 1 x 5704F Fire Status Panel card per control rack when fitted with and 5704F Fire card. Occupies 1 slot of control rack.

05704-A-0148 5704F Fire Status Panel

Interface Modules

05701-A-0120 Engineering Interface Lead

05701-A-0309 Master Alarm Update Module Kit

05701-A-0312 ModBus Interface Module Kit-RS 485/RS 422

05701-A-0313 ModBus Interface Module Kit-RS 232

05701-A-0314 Event Print Module Kit-RS 232

05701-A-0339 Master Alarm Update Panel

Single Way Rack

05701-A-0601 1W Rear Access Rack, Engineering Card, DC input, key set

8 Way Racks and Cabinets

05701-A-0452 Cabinet - Wall Mounting - 8 Way

05708-N-2008 8W Front Access Rack, 0 Blanking Panels

05708-N-3008 8W Front Access Rack, 0 Blanking Panels, 8W Cabinet

05708-N-5008 8W Front Access Rack, 0 Blanking Panels, 8W PSU - 50W

05708-N-6008 8W Front Access Rack, 0 Blanking Panels, 8W Cabinet, 8W PSU - 50W

05708-N-1008 8W Rear Access Rack, 0 Blanking Panels

05708-N-4008 8W Rear Access Rack, 0 Blanking Panels, 8W PSU - 50W

16 Way Racks and Cabinets

05701-A-0451 Cabinet - Wall Mounting - 16 Way

05716-N-2016 16W Front Access Rack, 0 Blanking Panels

05716-N-3016 16W Front Access Rack, 0 Blanking Panels, 16W Cabinet

05716-N-5016 16W Front Access Rack, 0 Blanking Panels, 16W PSU - 50W

05716-N-6016 16W Front Access Rack, 0 Blanking Panels, 16W Cabinet, 16W PSU - 50W

05716-N-1016 16W Rear Access Rack, 0 Blanking Panels

05716-N-4016 16W Rear Access Rack, 0 Blanking Panels, 16W PSU - 50W

Spare Rack Assembly Components

05701-A-0600 Sub rack Rear Access - 1 Way

05701-A-0506 Sub rack - Front Access - 8 Way

05701-A-0516 Sub rack - Rear Access - 8 Way

05701-A-0505 Sub rack - Front Access - 16 Way

05701-A-0515 Sub rack - Rear Access - 16 Way

Power Supplies

05701-A-0405 Power Supply Unit- AC To DC-16 Way- 50 Watts

05701-A-0406 Power Supply Unit- AC To DC-8 Way- 50 Watts

05701-A-0440 Power Supply Module- 50 W (Upgrade For PSU and Sub Units)

05701-A-0441 Power Supply Subunit- 50 Watts (Upgrade For 16 Way PSU)

Rack and Cabinet Accessories

05701-A-0365 Blanking Panel - Card Slot

05701-C-0471 Blanking Panel - 1U X 19" (16 Way)

05701-C-0474 Blanking Panel - 1U X ½ 19" (8 Way)

Spares

05701-A-0550 System 57 Calibration Plug

05701-A-0361 Engineering Card

05701-A-0325 DC Input Card

05701-A-0301 Single Channel Control Card - 4-20mA

05701-A-0302 Single Channel Control Card- Catalytic

05701-A-0351 Control Card- Single Channel- 5701

05701-A-0283 Sensor Drive Module - 4-20mA- 5701

05701-A-0284 Sensor Drive Module- Catalytic- 5701

05701-A-0285 Analogue Output Module- 5701

05701-A-0326 Field Interface Card (No Relays - Sensor Input Only)

05701-A-0327 Relay Card-Double SPCO- 5701 (A1. A2 and Fault Single Pole Changeover Relays)

05701-A-0328 Relay Card-Triple SPCO-5701 (A1. A2. A3 Fault and Inhibit Single Pole Changeover Relays)

05701-A-0329 Relay Card- Triple DPCO- 5701 (2xA1. 2xA2. 2xA3 Fault and Inhibit Single Pole Changeover Relays)

05701-A-0330 High Integrity Relay Card-Double SPCO -5701 (2xA1. 2xA2. 2xA3 Fault and Inhibit Single Pole Changeover Relays)

05701-C-0390 Interconnection Cable- 5701

05701-C-0127 Model 5701 Scale Label - Catalytic - 0-20% LEL

05701-C-0129 Model 5701 Scale Label - Catalytic - 0-50% LEL

05701-C-0130 Model 5701 Scale Label - Catalytic - 0-100% LEL

05701-C-0131 Model 5701 Scale Label - mA - 0-100% LEL

05701-C-0135 Model 5701 Scale Label - Catalytic - 0-4% V/V

05701-C-0137 Model 5701 Scale Label - mA - 0-25% V/V

05701-C-0138 Model 5701 Scale Label - mA - 0-30% V/V

05701-C-0139 Model 5701 Scale Label - mA - 0-100% V/V

05701-C-0141 Model 5701 Scale Label - mA - 0-10% V/V

05701-C-0145 Model 5701 Scale Label - mA - 0-5ppm

05701-C-0146 Model 5701 Scale Label - mA - 0-10ppm

05701-C-0147 Model 5701 Scale Label - mA - 0-15ppm

05701-C-0148 Model 5701 Scale Label - mA - 0-20ppm

05701-C-0149 Model 5701 Scale Label - mA - 0-25ppm

05701-C-0150 Model 5701 Scale Label - mA - 0-50ppm

05701-C-0151 Model 5701 Scale Label - mA - 0-100ppm

05701-C-0152 Model 5701 Scale Label - mA - 0-200ppm

05701-C-0154 Model 5701 Scale Label - mA - 0-500ppm

05701-C-0155 Model 5701 Scale Label - mA - 0-1000ppm

05701-C-0156 Model 5701 Scale Label - Catalytic - 0-2000ppm

05701-C-0157 Model 5701 Scale Label - Catalytic - 0-3000ppm

05701-C-0158 Model 5701 Scale Label - mA - 0-5000ppm

05701-C-0159 Model 5701 Scale Label - Catalytic - 0-10000ppm

05701-C-0160 Model 5701 Scale Label - Catalytic - 0-5000ppm

05701-C-0161 Model 5701 Scale Label - mA - 0-10000ppm

05701-C-0162 Model 5701 Scale Label - Catalytic - 0-15000ppm

05701-C-0163 Model 5701 Scale Label - Catalytic - 0-20000ppm

05701-C-0176 Model 5701 Scale Label - mA - 0-5 LELm

05701-C-0177 Model 5701 Scale Label - mA - 0-2% V/V

05701-C-0179 Model 5701 Scale Label - mA - 0-2ppm

05701-C-0180 Model 5701 Scale Label - mA - 0-30ppm

05701-C-0182 Model 5701 Scale Label - mA - 0-5% V/V

05701-C-0183 Model 5701 Scale Label - mA - 0-250ppm

05701-C-0184 Model 5701 Scale Label - mA - 0-2000ppm

05701-C-0185 Model 5701 Scale Label - mA - Blank Scale

05701-C-0186 Model 5701 Scale Label - Catalytic - Blank Scale

05701-C-0195 Model 5701 Scale Label - mA - 4-20mA

05701-C-0200 Model 5701 Scale Label - mA - 0-1000ppm

05704-A-0121 Quad Relay Interface Card - 5704 (4 SPCO Relays)

05704-A-0122 PCB Assembly relay expansion 4 channel

05704-A-0131 Relay Interface Assembly - 16 Relays - 5704 (12 SPCO, 4 SPST)

05704-A-0144 4 Channel Control Card- Catalytic

05704-A-0145 4 Channel Control Card- 4-20mA

05704-C-0160 Interconnect Cable- 5704

05704-C-0210 Model 5704 Scale Label - Catalytic - 0-100% LEL

05704-C-0240 Model 5704 Scale Label - mA - 0-100% LEL

05704-C-0247 Model 5704 Scale Label - mA - 0-25% V/V

05704-C-0263 Model 5704 Scale Label - mA - 0-50ppm

05704-C-0265 Model 5704 Scale Label - mA - 0-100ppm

05704-C-0266 Model 5704 Scale Label - mA - 0-200ppm

05704-C-0292 Model 5704 Scale Label - mA - 0-0.2ppm

05704-C-0293 Model 5704 Scale Label - mA - 0-0.4ppm

05704-C-0294 Model 5704 Scale Label - mA - 0-1.2ppm

05704-A-0123 5704F Hex Relay Interface Card

05704-A-0133 5704F Relay Interface Assembly

05704-A-0146 5704F Fire Card

05704-A-0148 5704F Fire Status Panel

Manuals

05701-M-5001 5701 System Manual (English)

05704-M-5001 5704 System Manual (English)

05704M5002 5704F System Manual (English)
