Kongsberg DPS 112MARITIME DGNSS SENSOR FOR WORLDWIDE OPERATIONS

MARITIME DGNSS SENSOR FOR WORLDWIDE OPERATIONS

DPS 112 is a robust and reliable DGNSS (DGPS/DGLONASS) sensor suitable for a wide range of marine

applications. It utilises the new Seastar SGG service capable of world wide sub-metre accuracy. Performance is independent of distance from reference stations.

Seastar SGG service

DPS 112 has been developed to utilise the new Global Satellite Based Augmentation System (Global SBAS) introduced by

Fugro Satellite Positioning, the Seastar SGG service. Unlike

regional SBAS services such as WAAS, EGNOS, GAGAN and

MSAS, and local DGPS services such as IALA DGPS, Seastar

SGG utilises Fugro’s own network of dual system reference

stations to calculate ‘orbit and clock’ corrections. The service

provides consistent sub-metre level accuracy positioning with

global validity.

DPS 112 is even capable of supplementing Seastar SGG corrections with regional SBAS and local IALA DGPS corrections.

GPS and GLONASS

One of the primary advantages of a combined GPS/GLONASS

system is the increased satellite coverage. The addition of

GLONASS increases system availability and the performance

of DPS 112 is greatly enhanced compared to traditional DGPS

systems when operating in highly obstructed environments and

under challenging signal tracking conditions.

A member of the DPS Family

The Kongsberg Seatex DPS product line is well-proven and

in use by professional marine and offshore users worldwide.

By complementing the DPS product line and introducing the

Seastar SGG service, Kongsberg Seatex and Fugro Satellite

Positioning extend the user segment to new and less complex

vessel categories.

The DPS product series is developed and suitable for all applications in need for a confident position solution when operating

in safety-critical environments.

The DPS 112 is an addition to the existing well proven DPS

range comprising DPS 132/232/432/4D/5D. The high end solutions offer decimetre level position accuracy, IMU integration

(DPS 4D/5D), application tailored HMI, extended DP operation

functionality and extended interfacing capabilities.

Applications

DPS 112 is a cost efficient DGNSS solution designed for users

where availability and reliability are paramount, with a meter-level position accuracy. DPS 112 has a built-in display for

easy system configuration and status monitoring.

An external display unit with an intuitive and easy-to-use graphical interface tailored for DP operations is avialable, forming an

ideal solution for workboats and platform support vessels.

FEATURES DPS 112

• Combined GPS L1/L2, GLONASS L1/L2 and SBAS receiver

• IALA beacon capability

• Built-in L-band receiver with Fugro Seastar SGG capability

• Optional standard RTCM correction input

• Easy software updates via USB

• Ethernet interface

• Embedded keypad and display

• Configurable output for external interfaces

• External display unit (optional)

TECHNICAL SPECIFICATIONS

PERFORMANCE

Global DGNSS position accuracy with: (*)

Seastar SGG service < 1 m

Regional DGPS position accuracy with: (**)

SBAS 1 to 2 m

IALA 1 to 3 m

Output rate 1 Hz

(*) Accuracy specifications (CEP 95 %) are based on real-life tests

conducted under low multipath conditions and an open view to the

sky. Tests at different locations under different conditions may produce

different results.

(**) Accuracy specifications(CEP 95 %) for SBAS (WAAS, EGNOS,

MSAS, GAGAN) are based on real-life tests conducted under low

multipath conditions and an open view to the sky within the respective

SBAS service coverage areas.

INTERFACES

Serial ports 3 serial ports (2 NMEA output,

 1 RTCM input), RS-232 or

 RS-422 (galvanically isolated)

Ethernet/LAN 1

USB 3

DATA OUTPUTS

Message formats NMEA 0183 v. 3.0

Message types GGA, GLL, GSA, GST, GSV, VER,

 VTG, ZDA

DATA INPUTS

Data inputs RTCM-SC104 ver. 2.2 and 2.3

WEIGHT AND DIMENSIONS

DPS 112 unit 5.8 kg, 89 mm x 444 mm x 357 mm

GNSS antenna 0.5 kg, 69 mm x 185 mm

IALA antenna 0.78 kg, 870 mm

Spotbeam antenna 1.4 kg, 96 mm x 150 mm

POWER SPECIFICATIONS

DPS 112 unit 100 - 240 V AC 50/60 Hz, max 60 W

GNSS antenna 5 V DC from processing unit

IALA antenna 10.2 V DC from processing unit

Spotbeam antenna 12 V DC from processing unit

ENVIRONMENTAL SPECIFICATIONS

Operating temperature range

DPS 112 unit -15 to +55 °C*)

GNSS antenna -40 to +85 °C

IALA antenna -55 to +70 °C

Spotbeam antenna -30 to +70 °C

*) Recommended +5 to +40 °C

Humidity

DPS 112 unit Max. 95 % non-condensing

GNSS antenna Hermetically sealed

IALA antenna Hermetically sealed

Spotbeam antenna Hermetically sealed

Mechanical

Vibration IEC 60945/EN 60945

Electromagnetic compatibility

Compliance to EMCD,

immunity/emission IEC 60945/EN 60945

PRODUCT SAFETY

Compliance to LVD,

standard used IEC 60950-1/EN 60950-1
