Abaco VSR8000 Fully Rugged, COTS System Secure Router

VSR8000

Fully Rugged, COTS System Secure Router

Overview

The VSR8000 is a fully rugged secure router featuring Juniper Networks® Junos® vSRX Virtual Firewall and eight 1000BASE-T Ethernet ports.

 It is a commercial off the shelf (COTS) SWaP-optimized line replaceable unit (LRU) version of the recently launched VSR347D 3U VPX secure router.

 The VSR8000 is a rugged standalone COTS system suitable for a wide range of operating environments.

Advanced Security Environment

Juniper Networks Junos vSRX provides a wealth of features including IPsec VPN, NAT, QoS, and full routing capabilities, to name just a few.

The advanced security features offered by vSRX come from Juniper Networks experience as a company aimed at delivering automated, scalable and secure networks.

Tech Insertion: for existing RTR8GE installations

The VSR8000 allows existing RTR8GE users to seamlessly integrate new, higher performance hardware technologies while retaining form, fit and function and application software compatibility.

Rugged and ready

With high levels of environmental qualifications, the VSR8000 meets extreme demands presented by altitude,

 decompression, overpressure, shock, and vibration. It is qualified to MIL-STD-810H for rain, sand, and salt fog.

This secure router can be utilized on a wide range of applications, including edge of network security, command and control,

fire control, electronic warfare, radar, surveillance, situational awareness, imaging, AI and autonomy, rugged industrial and transportation, and other high-performance embedded computing applications.

Specifications

Cooling  Base Plate, Conduction

Ethernet  8 x 10/100/1000 BaseT

Form Factor  Boxed System

I/O   COM, Gigabit Ethernet, USB

Network Operations

Firewalling, IPv4. IPv6 routing

Product Type

Virtual Secure Router

Serial I/O

2

Software

Virtual Firewall, Juniper Networks®, Junos®, vSRX

Temp Range

-40°C to 71°C at the base plate

Qualifications:

MIL-STD-461G – EMI, EMC, and ESD, MIL-STD-704F – Power and Holdup, MIL-STD-810H – Shock, Vibration, Water Tightness (Rain), Sand, and Salt Fog, RTCA DO-160G – Humidity, Altitude, Decompression, and Overpressure

Maximum Router Performance:

Routing+Firewall+NAT (64-byte packets) – 340Kpps, AES256+SHA256 VPN – 300Mb/s, Boot time – typically less than 290 second
