ABB Panel 800 Version 6- PP885

AllPanel800Version6aredevelopedtosatisfythedemandsofhuman-machine

communication.  Built-in functions such as displaying and controlling text, dynamic

indication, time channels, alarm and recipe handling are included.

The Panel 800 Version 6 works primarily in an object-oriented way, making it easy

to understand and use.  Configuration is carried out on a PC using the Panel Builder

configuration tool.  The project can then be transferred and stored in the operator

panel itself.

Theoperator panel is designed for stationary installation on a planar surface,

where the following conditions are fulfilled:––––

no high explosive risks

no strong magnetic fields

no direct sunlight

no large, sudden temperature changes

• Installthe operator panel according to the accompanying installation instructions.

• Ground the operator panel according to the accompanying installation

instructions.

• Onlyqualified personnel may install the operator panel.

• Separate the high voltage, signal and supply cables.

• Makesure that the voltage and polarity of the power source is correct before

connecting the operator panel to the power outlet.

• Peri

pheral equipment must be appropriate for the application and location.

• InaZone2environment, this equipment shall be installed in an enclosure that

provides a degree of protection not less than IP 54 or greater than IP 65 in

accordance with IEC/EN 600079-0.   The IP rating of the equipment is limited to

the IP rating of the enclosure it is to be installed into.

• InaZone 22 environment, this equipment shall be installed in an enclosure

that provides a degree of protection not less than IP 64 or greater than IP 65 in

accordance with IEC/EN 600079-0.   The IP rating of the equipment is limited to

the IP rating of the enclosure it is to be installed into.

During Use

• Keepthe operator panel clean.

• Emergency stop and other safety functions may not be controlled from the

operator panel.

• Donotuseexcessive force or sharp objects when operating the touch screen.

Service and Maintenance

• Onlyq

ual

ified personnel should carry out repairs.

• Theagreed warranty applies.

• Before carrying out any cleaning or maintenance operations, disconnect the

equipment from the electrical supply.

• Clean the display and surrounding front cover with a soft cloth and mild

detergent.

• Replacing the battery incorrectly may result in explosion.  Only use batteries

recommended by the supplier.  During the warranty period, the battery needs to

be replaced by an authorized ABB service center.

Dismantling and Scrapping

• Theoperator panel or parts thereof shall be recycled according to local

regulations.

• Thefollowing components contain substances that might be hazardous to health

and the environment: lithium battery, electrolytic capacitor and display.

Appearance of Air in Touch Screen

The layer structure of the touch screen contains air and in rare cases appearance of

bubbles can arise.  This is purely cosmetic and does not affect any functionality of the

operator panel.  The appearance can occur under certain environmental conditions

such as temperature, humidity, and atmospheric pressure.
