N-Tron® NT24k 24-Port, Dual Redundant VDC Power Input, Rackmount Gigabit Managed Industrial Ethernet Switch

Item number NT24K-DC2

The N-Tron® NT24k 24-Port, Dual Redundant VDC Power Input, Rackmount Gigabit Managed Industrial Ethernet Switch is one of the easiest to deploy Ethernet switches in the industry. Simplified use, uncompromised performance and multiple configurations to fit your automation and industrial needs. Features has 3 modular expansion slots, a modular rackmount design and two redundant 18-49 VDC power inputs.

Features and benefits

• Rugged and durable design

  Operates in extreme temperatures from -40° C to 85° C, has high shock and vibration tolerance, ESD and surge protection. Designed to handle the most demanding environments.

• Extensive industry certifications

  With extensive compliance certifications, the switch is ideal for a wide range of industrial applications in factory automation, utilities, SCADA, security surveillance, transportation and more.

• Customizable configurations to connect your data

  Up to 24 Gigabit ports with 8-port hot-swappable module option including 10/100/1000BaseT(X) copper, 100Base fiber, 1000Base fiber, Gigabit SFP and dual mode SFP (100Base/1000Base). Modules sold separately.

• Reliable connectivity to industrial data

  The N-Tron NT24k managed Ethernet switch connects industrial operations to data reliably and efficiently. It provides an industry-ready way to move data across industrial networks.

• Robust security for your network switches

  Protect against unauthorized access with built-in security features: IEEE 802.1X port and user authentication (RADIUS), SNMPv3 communication protocol, SSH/SSL/HTTPS, MAC security and support for event logs and syslogs.

• Designed with network redundancy to maximize uptime

  High availability protocols (STP/RSTP/MSTP, N-Ring), VLANs, Quality of Service (QoS), port trunking and mirroring, IGMP and LACP maximize uptime and keep mission critical operations running

• Fast Healing Ring and RSTP/MSTP network redundancy

  Comes with N-Tron’s N-Ring™ ~30ms healing technology. Pre-configured N-Ring ports make it easy to add new NT24k-series switches. Reconfigure by changing the ring from “auto-member” to “manager.”

• Design enhancements to simplify VLAN configuration

  Ease of use enhancements make VLAN configurations easier than ever. The graphical display shows a logical view of the switch, including the VLAN port and tag configuration.

• N-View™ monitoring technology

  Monitor multiple N-View™-capable switches from a single window. This Windows-based software reduces downtime by centralizing firmware management, grouping devices and scheduling firmware updates.

• Advanced features designed to meet future needs

  With advanced management, performance and security features provided right out of the box, you have tools you need now—and as your network needs grow.
