N -Tron® 712FXE4-SC-15-HV Managed 12-port Industrial Ethernet Switch

Item number 712FXE4-SC-15-HV

The N -Tron® 12-port Managed Industrial Ethernet Switch is a powerful and durable solution to connect Ethernet-enabled equipment. Best-in-class network management features for remote monitoring and configuration control. High performance, reliability and noise immunity for rugged industrial applications. Eight copper 10/100 ports + four 100Base 15km, multimode fiber ports with SC connector.

Features and benefits

• Easily connect and manage Ethernet-enabled devices

  Store-and-forward technology and superior switch performance in industrial applications where ruggedness and extended distances are required.

• Designed for rugged environments

  Hardened metal DIN-rail enclosure delivers top performance in demanding environments. High shock and vibration ratings. Case dimensions: 4.3” X 3.1” X 4.6”.

•

• Flexibility with both copper and fiber ports

  Eight 10/100BaseTX RJ-45 ports and four singlemode 100BaseFX fiber optic ports with SC connectors.

• Easy to use and flexible 10/100BaseTX ports

  Auto-sensing for duplex and MDIX. Auto-configurable for maximum speed by default. Can also be hard coded. Wire speed capability on all 10/100BaseTX ports.

• Easy to configure management functionality

  Fully managed features are easily configurable from a web browser. Set up SNMP, VLAN, Quality of Service (QoS), port trunking, port mirroring, IGMP, SNMP and RSTP to your specifications.

• DHCP Server for Automatic IP address assignment

  DHCP Server assigns IP addresses automatically. Includes DHCP Option 82 relay, Option 61 and IP fallback.

• Switch status monitoring and LED indicators

  LED indicators are configurable to indicate power failure and N-Ring status.

• Leading certifications for industrial environments

  IEEE 1613 compliance. Suitable for hazardous environments with UL Class I, Division 2 listing and CE certifications. Over 2 million hours MTBF and operating temperature of -40 °C to 70 °C.

• Real-time remote monitoring

  N-View™ Windows-based software provides remote monitoring.

• N -Ring™ technology with ~30ms healing time

  N-Ring™ technology offers expanded ring size capacity to support up to 250 N-Tron managed switches. The ring manager provides complete fault diagnostics and ring health status via browser.

• Enhanced Port Security

  Port-based MAC address filtering delivers a high level of security to your network connections. Supports up to 8,000 MAC addresses.

• Redundant power inputs and surge protection

  Redundant power input (43-300 VDC). ESD and surge protection diodes on all ports.
