ABB CP555 1SBP260179R1001 Product Overview

ABB CP555 (1SBP260179R1001) Product Overview

The ABB CP555 is a high-performance Human Machine Interface (HMI) from the CP500 series. Designed for industrial environments, it provides a robust platform for operators to monitor and control complex automation processes.

With its vibrant display and reliable processing power, it bridges the gap between the PLC (Programmable Logic Controller) and the operator.

Product Advantages and Features

Exceptional Clarity: The 10.4" TFT display ensures that complex schematics and data trends are legible even in high-glare industrial settings.

Rugged Design: Built with an IP65-rated front face, it is resistant to dust and water splashes, making it ideal for harsh factory floors.

Multi-Protocol Support: It seamlessly integrates with ABB’s AC500 PLC range and supports third-party protocols for flexible system architecture.

User-Friendly Programming: Compatible with standard ABB HMI software, allowing for drag-and-drop screen design and rapid deployment.

Application Cases

Manufacturing Lines: Used for real-time tracking of production metrics, alarm management, and machine speed adjustments.

Water Treatment Plants: Monitoring flow rates, tank levels, and valve statuses through intuitive graphical representations.

Food & Beverage: Managing recipe parameters and sterilization cycles where washdown-resistant equipment is required.

Unique Product Description

The ABB CP555 isn't just a screen; it's the "brain's window." While many HMIs focus solely on display, the CP555 emphasizes communication stability.

 Its 1SBP260179R1001 variant is specifically engineered for low-latency feedback, ensuring that when an operator hits "Emergency Stop" or adjusts a setpoint,

 the PLC reacts within milliseconds. It combines the aesthetic of modern tech with the "bulletproof" reliability expected of ABB industrial hardware.

Related & Other Models in the Series

Model Number    Screen Size    Characteristics

CP501    3.5"    Compact, Monochrome

CP502    5.7"    Mid-range, STN Color

CP511    10.4"    High Performance, TFT

CP552    10.4"    Keypad + Touch variant

Installation and Maintenance

Installation: Ensure the cutout dimensions match the manual specifications exactly. Use the provided mounting clamps to maintain the IP65 seal against the cabinet door.

Wiring: Always ground the unit to prevent EMI (Electromagnetic Interference). Use shielded cables for RS485/Ethernet communication.

Maintenance: Clean the touchscreen with a soft, dry cloth or mild detergent. Avoid using sharp objects or harsh chemicals (like acetone) which can degrade the touch membrane.

Backup: Regularly export project files and system logs via the USB or Serial port to prevent data loss during hardware migrations.
