See the controller installation instructions for more information about

using these utilities to load firmware. If you load firmware via an

EtherNet/IP connection, browse through the Ethernet port, across the

virtual backplane, and select the 1769-L35E controller.

Loading 1769-SDN Firmware

If you are using a 1769-L35E controller and a 1769-SDN scanner for

DeviceNet communications and want to take advantage of the new

explicit messaging feature, you must also upgrade the scanner’s

firmware to revision 2.2 or later. The updated firmware is available

with RSLogix 5000 software or you can download it from the support

website. Use the ControlFlash utility (as described above) to load the firmware.

You must use a DeviceNet connection to update the 1769-SDN

firmware to revision 2.2. After the firmware is updated to revision 2.2,

subsequent updates to the 1769-SDN firmware can be initiated via a

controller backplane connection.

Hold Last State and

User-Defined Safe State

Not Supported

When 1769 Compact I/O modules are used as local I/O modules in a

CompactLogix system, the local I/O modules do not support the Hold

Last State or User-Defined Safe State features, even though you can

configure these options in the programming software.

• If a local I/O module fails such that its communication to the

controller is lost, or if any module is disconnected from the

system bus while under power, the controller will go into the

fault mode. All outputs turn off when the system bus or any

module faults.

• RSLogix 5000 software creates tags for modules when you add

them to the I/O configuration. The 1769 module tags define

configuration (C) data type members which may include

attributes for alternate outputs. CompactLogix does not enable

local modules to use the alternate outputs. Do not configure the

attributes listed below:

Any 1769 Compact I/O modules used as remote I/O modules in a CompactLogix system do support the Hold Last State and User-Defined Safe State features.

ATTENTION:

•Before installing, configuring, operating or maintaining this product, read this

document and the documents listed in the Additional Resources section for

installing, configuring, or operating equipment. Users should familiarize

themselves with installation and wiring instructions in addition to requirements

of all applicable codes, laws, and standards.

• Installation, adjustments, putting into service, use, assembly, disassembly, and

maintenance shall be carried out by suitably trained personnel in accordance with

applicable code of practice. In case of malfunction or damage, no attempts at repair

should be made. The module should be returned to the manufacturer for repair. Do not

dismantle the module.

• This equipment is certified for use only within the surrounding air temperature range

of 0…60 °C (32…140 °F). The equipment must not be used outside of this range.

• Solid state equipment has operational characteristics differing from those of

electromechanical equipment. Safety Guidelines for the Application, Installation and

Maintenance of Solid State Controls, publication SGI-1.1, available from your local

Rockwell Automation sales office or online at

http:/www.rockwellautomation.com/literature describes some important differences

between solid state equipment and hard-wired electromechanical devices.
