6AV6642-0DA01-1AX0 Siemens SIMATIC HMI TP700 Comfort Touch Panel

From: | Author:Huang | Time :2025-06-04 | 295 Browse: | 🔊 Click to read aloud ❚❚ ▶ | Share:
6AV6642-0DA01-1AX0
Siemens SIMATIC HMI TP700 Comfort Touch Panel

Product Overview

The Siemens 6AV6642-0DA01-1AX0 is a high-performance 7-inch SIMATIC HMI TP700 Comfort touch panel designed for industrial automation applications. This advanced human-machine interface combines intuitive operation with robust industrial-grade reliability.

Key Features

• 7" TFT color display with 16 million colors
• Resistive touchscreen technology
• Integrated Ethernet interface
• Windows CE 6.0 operating system
• IP65 front panel protection

Technical Architecture

Built on a powerful ARM-based processor architecture, the TP700 Comfort delivers exceptional performance for demanding industrial applications. The device features optimized memory management and efficient data processing capabilities.

Technical Specifications

ParameterSpecification
Display Size7" TFT LCD
Resolution800 × 480 pixels
Colors16.7 million
Backlight Life50,000 hours
Operating Temperature0°C to +50°C
Storage Temperature-20°C to +60°C
Protection ClassIP65 (front), IP20 (rear)
Power Supply24V DC
Power ConsumptionMax. 25W


Industrial Applications

The 6AV6642-0DA01-1AX0 serves as a critical interface component across diverse industrial sectors, enabling efficient monitoring and control of automated systems.

🏭

Manufacturing

Production line monitoring and process control

⚡

Energy & Utilities

Power distribution and grid management systems

🚰

Water Treatment

SCADA systems for water and wastewater management

🚢

Marine & Offshore

Ship automation and offshore platform control

🏗️

Building Automation

HVAC, lighting, and security system integration

🔬

Process Industries

Chemical, pharmaceutical, and food processing

Connectivity & Integration

Communication Interfaces

The TP700 Comfort features comprehensive connectivity options including Ethernet TCP/IP, PROFINET, and serial communication interfaces. This enables seamless integration with various industrial protocols and networking architectures.

Software Compatibility

Compatible with SIMATIC WinCC (TIA Portal), the panel supports advanced visualization capabilities, alarm management, and data logging functions. The integrated web server allows remote access and diagnostics.

Protocol Support

• PROFINET
• Ethernet/IP
• Modbus TCP
• OPC UA
• S7 Communication

Performance & Reliability

Environmental Robustness

Engineered for harsh industrial environments, the panel withstands vibrations, electromagnetic interference, and temperature fluctuations while maintaining consistent performance.

Maintenance Features

The device incorporates self-diagnostic capabilities, remote maintenance functions, and comprehensive logging features to minimize downtime and optimize operational efficiency.

Quality Standards

Certified according to international standards including CE, UL, and cUL, ensuring compliance with global industrial safety and quality requirements.

Related SIMATIC HMI Models

Explore other models in the SIMATIC HMI Comfort series for various application requirements:

6AV6642-0BC01-1AX0
TP700 Comfort - Basic Version
6AV6642-0DC01-1AX0
TP700 Comfort - Extended Version
6AV6644-0AB01-2AX0
TP900 Comfort - 9" Display
6AV6644-0AA01-2AX0
TP900 Comfort - Standard
6AV6646-0AB01-2AX0
TP1200 Comfort - 12" Display
6AV6648-0BC11-3AX0
TP1500 Comfort - 15" Display
