GE IS420ESWBH3A IONET Switch Module

IS420ESWBH3A

IS420ESWBH3A IONET Switch Module

About the IS420ESWBH3A

possesses specific applications across a range of different products:

wind turbine assemblies

steam turbine assemblies

gas turbine automated drive assemblies

can additionally be identified as a desirable GE Mark Series

one of the lastly-developed GE product series to make use of the patented Speedtronic control system technology

IS420ESWBH3A Product Number Breakdown

Industrial Ethernet Switch IS420ESWBH3A is part of the Mark VIe Safety Control System designed by General Electric.

This switch does not have any fiber ports but has sixteen copper ports, the copper ports are 10/100Base-TX RJ45 ports.

The primary operation of the switch is to perform as a level one Ethernet switch which will center on the capability to buffer multi-cast and broadcast packets.

There should be enough space to allow for the buffer of one packet per port;

if multiple incoming streams are being sent to the switch, it can only accept one incoming stream out of the multiple streams and will buffer the remaining streams for later transmission.

The IS420ESWBH3A functional product number begins with a dual-functioning initial naming segment in the IS420 series tag delegating this IS420ESWBH3A Mark VIe Series product's special modular Mark VIe Series assembly version as well as its domestic location of original GE manufacture.

Some of the other relevant hardware details that can be discovered through analysis of functional product number include this IS420ESWBH3A PCB's:

ESWB product acronym

Conformal PCB coating style

Group three Mark VIe Series product grouping

A-rated primary functional product revision

Diagnostic Tips and Specifications

There are LED indicators on the IS420ESWBH3A switch.    There also exists:

a power LED

activity and link LEDs

When the link LED is solid yellow it indicates that a 10 MB link is being used

when solid green a 100 MB link is being used

no LED light indicates that there is no link.
