IC660BBA025

Part Number IC660BBA025 Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockIC660BBA025 is a Genius I/O Module developed by GE, part of the Mark I and II control systems. This 24/48 VDC analog current source block provides reliable analog output capabilities with six analog output circuits, each capable of producing a 4 to 20 mA current loop. The module requires no calibration, simplifying its integration into various systems. Features Analog Output Circuits: Six outputs support 4 to 20 mA current loops. Voltage Application Capability: Outputs 5 and 6 can be used for voltage applications. Internal Power Supply: Powers all circuits internally; no external power is needed for 4 to 20 mA signals. Current Loop Control: Each output independently manages a 4 to 20 mA current loop. Advanced Diagnostics: Real-time fault messages can be cleared using a handheld monitor or CPU. Digital Output: Includes a dedicated output for driving a Bus Switching Module. Installation and Safety Protective Enclosure: The module must be installed in a protective enclosure to shield it from airborne contaminants. Clean Environment: Ensure the installation area is clean and free from contaminants. Cooling and Airflow: Adequate cooling and airflow must be ensured to prevent overheating. Configuration Process Handheld Monitor: Use the IC66 HHM501G model (version 4.0 or later) for configuration. Device Number: Input the device number (serial bus address) into the monitor. Reference Number: Enter the reference number if required. Scaling Configuration: Adjust the scaling to set the corresponding output signal values. Offline Configuration: Properly ground the block and install a 75 Ohm resistor across Serial 1 and 2 terminals if configuring offline. Maintenance and Troubleshooting Fault Management: Use advanced diagnostics for real-time fault messages and clear them via the handheld monitor or CPU. Power Disconnection: Ensure power is disconnected before handling to avoid electrical shock hazards. Resistor Installation: Install a 75-ohm resistor across Serial 1 and 2 terminals during offline configuration to ensure proper operation.24/48 VDC ANALOG OUTPUT BLK
