IC697PWR711

Part Number IC697PWR711 Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockThe IC697PWR711 is a Power Supply Module developed by GE Fanuc. It is a 100 Watt Power Supply Module designed for the Series 90-70, providing reliable power options for industrial automation systems. Power Supply Specifications The module operates with 120 VAC, 240 VAC, or 125 VDC inputs. It delivers +5 VDC at up to 20 amps, +12 VDC at up to 2 amps, and -12 VDC at up to 1 amp, supporting a range of electronic components and devices. Design and Construction Features It features a slide-in rack mount design, compatible with standard IC697 and VME Integrators racks, connecting via a 48-pin backplane-mounted connector. Supports powering a single rack or a second rack if the total load is within the modules rating, with a prewired cable for easy interconnection. The power supply ensures operation through at least one input line cycle loss at full load and includes protection for overcurrent and overvoltage conditions. Other Features The module incorporates Power Factor Correction (PFC) for AC inputs, enhancing efficiency and reducing reactive power demand. It operates within a range of 90 VAC to 264 VAC for AC inputs and 100 VDC to 150 VDC for DC inputs, providing flexibility for different power sources. The power supply requires derating at low line voltages or high temperatures for continuous operation exceeding one hour to prevent overheating. Installation Insert the module into the leftmost slot of any IC697 or VME Integrators rack, ensuring power is off during installation to avoid hazards. Configure the module according to the power requirements of the connected system to ensure it meets the load demands effectively.POWER SUPPLY 120/240
