Introduction

Harmony tag objects are configured from the TagConfig Aspect in the Control

Structure inside the Workplace. This section describes the common aspect views of

the Harmony objects.

TagConfig Aspect View

All TagConfig Aspect views have the same general appearance and behavior. The

aspect views are divided into three common areas of Tabs, Body, and Footer.

Tabs

The tabs associated with the Aspect view depend on the type of object that is

selected for Harmony. Harmony data that is common to multiple object types is

presented in the same way to help make Harmony tasks easier and to improve

efficiency. The General tab is included for every object type.

Body

The body area contains all of the configurable properties of any selected tab.

Footer

The footer area contains controls to apply or cancel changes.

800xA for Symphony Plus Harmony communicates with the control systems  through a Cnet-to-computer interface (IET800, PNI800).

800xA for Symphony Plus Harmony is a distributed process management and  control system.

Using a series of integrated Harmony control units, the system  allows monitoring and control of process variables such as flow rate,

temperature,  and pressure according to a control configuration that the engineer or technician  defines.

A Harmony control unit is a controller and its I/O devices connected for  communication on control network (Cnet).

800xA for Symphony Plus Harmony operates in a Windows environment on  personal computer hardware.

Using interactive process graphics, the operator can  monitor and control all Analog loops and Digital devices interfaced to the network  through Harmony control units.

800xA for Symphony Plus Harmony provides maintenance personnel with the  capability to globally monitor

the operating status of any system component on the  network, and to diagnose component failures from any workstation.

800xA for Symphony Plus Harmony also provides the Harmony Executive Service.

It is an 800xA service that controls underlying 800xA for Symphony Plus Harmony  services.

Changes to Configuration in 800xA for Symphony Plus  Harmony

The following configuration related changes have been made to 800xA for  Symphony Plus Harmony in the 6.0 release:

• The SQL Server based ConfigServer Database that contained 800xA for

Harmony Configuration data has been eliminated in the 6.0 release. The tag

configuration data is now stored in the Aspect Directory.

• The Harmony Synchronizer Aspect, Tag Importer Exporter, and Import Export

Configuration utility have been eliminated. A new Harmony Uploader Aspect

has been added to allow Harmony tag configuration data to be imported to and

exported from the Aspect Directory.

• A new TagConfig Aspect that supports Aspect Directory based tag

configuration has been added. The new TagConfig Aspect also provides

support for 800xA Engineering Environments and Versioning.

• The System Definition object type located under the Harmony OPC Server

Network object has been eliminated. It has been replaced with a new INFI 90

System Definition object in the Library Structure and a new ServerConfig

aspect on the Harmony OPC Server Network object.

• Remote Motor Control Block (RMCB) Text configuration has been removed

from the Harmony Server TagConfig Aspect. RMCB Text configuration is now

provided by a new NLS Text Set on the new INFI 90 System Definition object

in the Library Structure.

• The Harmony Bulk Configuration Manager has been eliminated. The 800xA

Bulk Data Manager can now be used to make bulk changes to 800xA for

Symphony Plus Harmony TagConfig Aspects.

• The 800xA for Harmony Backup/Restore utility has been eliminated. 800xA

for Symphony Plus Harmony tag configuration data can now be backed up and

restored through the standard 800xA Aspect Directory backup/restore.

• The Harmony Server Monitor object and TagMonitor Aspects are no longer

needed and have been eliminated.
