1SBP260171R1001 CP502 Text Display Panel

The CP502 Text Display Panel, a significant innovation from ABB, is designed to work in tandem with the ABB Advant Controller 31 and ABB Advant OCS. This control panel serves as a crucial interface between operators and the industrial control systems it is associated with. The panel features 3 programmable keys and 8 function keys. These keys offer a high degree of flexibility and customization. The programmable keys allow users to assign specific functions or commands according to their operational needs. The 8 function keys, on the other hand, provide quick access to frequently used operations or system settings. This combination of keys simplifies the control process, enabling operators to interact with the industrial equipment more efficiently and precisely.

The LCD text display, which has 2 lines and 20 characters, is another notable aspect. It presents clear and concise text information, allowing operators to easily view important data such as system status, process variables, and error messages. The display's size and format are optimized for quick comprehension, ensuring that operators can make informed decisions promptly. With an estimated shipping size of 4.0" x 2.0" x 6.0" (10.2 cm x 5.1 cm x 15.2 cm) and a weight of 0 lbs 12.9 oz (0.4kg), the CP502 is relatively compact and lightweight. This makes it convenient for installation in control cabinets or on operator consoles. The associated Tariff Code of 8518510000 classifies it within a specific category for customs and international trade purposes. Originating from Sweden and shipping from Webster NY, USA, it has a global supply chain footprint. The CP502 Text Display Panel is an essential tool for enhancing the usability and control of ABB's industrial automation systems.
