Bently Nevada 2300/20-RU 2300/20-CN Monitoring controller

2300/20

l Two 4-20 mA outputs with internal current loop power supply.

l Continuous monitoring and protection l Two acceleration/velocity/proximity inputs with synchronized sampling for advanced diagnostics.

l One dedicated speed channel supporting Proximity probes, Magnetic

pickup and Proximity switch type sensors.

l Supports process variable on all three

input channels.

l Key measurements (Acceleration pk, Acceleration rms, Velocity pk, Velocity

rms, Displacement pp, Displacement rms, Speed) real-time provided with alarm

configuration.  l Each channel has one measurement

group, and can add additional two

bandpass measurements and several nX measurements (depends on the device

availability).

l LCD and LED for real time value and

status display.  l Ethernet 10/100 Base-T communication

for configuration using Bently Nevada Monitor Configuration software

(Included) with RSA encryption.  l Local contacts for positive engagement

of monitor bypass, configuration lockout, and latched alarm/relay reset.

l Two relay outputs with programmable

setpoints.  l Three buffered transducer outputs

(including Keyphasor signal) providing short circuit and EMI protection.  Buffered

outputs for each signal are through BNCconnectors.

l Modbus over Ethernet.

l Alarm Data Capture
