Principle of operation:
The turbine sensor and preamplifier form an oscillator, the amplitude of which attenuates with the proximity of the sensor probe to the metal DUT,
the amplitude of attenuation being proportional to the distance between the sensor and the DUT.
The sensor and preamplifier are linearly calibrated at the factory in sets using calibration material 42CrMo4.
so no further calibration is required for installation.
The user only needs to adjust the air gap between the sensor and the measuring surface until the desired signal is obtained from the output of the preamplifier.
Sensor Models:
To meet a variety of measurement needs and environmental requirements, EPRO offers a wide selection of turbine sensor models and configurations.
Sensors are available with mounting threads or rectangular mounting flanges.
The measuring range is from 1mm to 20mm.
Thread sizes are ф6mm, ф10mm and ф18mm metric or imperial.
Depending on the model, the sensors are available in the following options:
1. Different thread lengths;
2. The end of the cable can be selected from self-locking waterproof connector or bare wire method;
3. The cable can be selected as armored or non-armored;
4、Connector or non-connector can be selected at 1m cable;
5、Applicable temperature: -35℃-+380℃.
Application areas: the company distributes products used in CNC machinery metallurgy,
oil and gas, petrochemical chemical industry, papermaking and printing, textile printing and dyeing, machinery,
electronics manufacturing, automobile manufacturing, tobacco, plastic machinery.
Electric power, water conservancy, water treatment / environmental protection, municipal engineering, boiler heating, energy, power transmission and distribution.
