Stratix 2000 Unmanaged Ethernet Switches: A Detailed Description

1. Introduction

2. Physical Design and Construction

• Compact and Rugged Design: The Stratix 2000 Unmanaged Ethernet Switches typically feature a compact form factor, which allows for easy installation in tight spaces within industrial control cabinets or on machine frames. Despite their small size, they are built with robust materials like high-quality metal alloys or durable plastics that can withstand the harsh conditions commonly encountered in industrial settings. This includes protection against dust, moisture, vibration, and extreme temperatures, ensuring reliable operation and a long lifespan even in challenging environments.

• Port Configuration: These switches come with a variety of port options to accommodate different networking requirements. They usually have multiple Ethernet ports, which can range from a few ports (such as 4 or 5 ports) for smaller-scale applications to a larger number of ports (e.g., 8, 16, or even more) for systems that need to connect numerous devices. The ports are designed to support different Ethernet standards, such as 10/100/1000Base-T, allowing for compatibility with a wide range of devices operating at various speeds. Some models may also offer ports with different connector types, like RJ45 connectors for standard copper cabling, to ensure flexibility in network cabling and device connection.
• Mounting Options: The Stratix 2000 Unmanaged Ethernet Switches provide flexible mounting solutions. They can be easily mounted on DIN rails, which is a common and convenient method in industrial control panels, enabling quick and straightforward installation and removal. Additionally, they may also support panel mounting for more customized installations, depending on the specific needs of the application. This versatility in mounting allows for seamless integration into different industrial setups, whether it's in a factory floor, a process control room, or an outdoor installation in an industrial site.

3. Network Connectivity and Performance

• Plug-and-Play Operation: One of the key features of these unmanaged switches is their plug-and-play functionality. They do not require any complex configuration or setup by the user. Once powered on and connected to the network devices, they automatically start forwarding Ethernet frames between the connected ports, enabling immediate data communication. This simplicity makes them ideal for applications where quick installation and minimal maintenance are essential, such as in small to medium-sized industrial automation systems or in situations where technical expertise for network configuration might be limited.
• Data Transfer Rates: The Stratix 2000 Unmanaged Ethernet Switches support industry-standard Ethernet data transfer rates. Depending on the port configuration and the specific model, they can handle speeds of 10 Mbps, 100 Mbps, or 1000 Mbps (1 Gbps). This allows for efficient data transmission between devices, whether it's for sending control commands from a PLC to an actuator or for transferring real-time monitoring data from sensors to an HMI. The switches are designed to handle the typical data traffic patterns in industrial environments, ensuring smooth and uninterrupted operation even during peak usage periods.
• Switching Capacity and Throughput: These switches possess sufficient switching capacity and throughput to manage the data flow within the network. The switching capacity refers to the total amount of data that the switch can handle per unit of time, while the throughput indicates the actual rate at which data can be successfully transmitted through the switch. The Stratix 2000 Unmanaged Ethernet Switches are engineered to meet the demands of industrial applications, with switching capacities and throughputs that are adequate to support multiple devices communicating simultaneously without significant bottlenecks or data loss.
