ABB 2VAA008417R1 cHBS01-FPH Base Single Fld Pwr Hot

Features and benefits

Termination for up to eight (8) analog I/O process signals within a horizontal row.

All SD I/O modules & bases of all types (Singular or Redundant) AND (Compact or Full-size), are

100% fully compatible with each other. Thus, Singular & Redundant, Compact or Full-size I/O

modules can be mounted within a single, common HN800 I/O bus.

Optional mechanical keying can be implemented to prevent insertion of the wrong I/O module

type.

Latching device on the base locks the base into position on DIN-Rail.

Industry standard 35-mm DIN rail, Horizontal row mounting.

Changes to Configuration in 800xA for Symphony Plus  Harmony

The following configuration related changes have been made to 800xA for  Symphony Plus Harmony in the 6.0 release:

• The SQL Server based ConfigServer Database that contained 800xA for

Harmony Configuration data has been eliminated in the 6.0 release. The tag

configuration data is now stored in the Aspect Directory.

• The Harmony Synchronizer Aspect, Tag Importer Exporter, and Import Export

Configuration utility have been eliminated. A new Harmony Uploader Aspect

has been added to allow Harmony tag configuration data to be imported to and

exported from the Aspect Directory.

• A new TagConfig Aspect that supports Aspect Directory based tag

configuration has been added. The new TagConfig Aspect also provides

support for 800xA Engineering Environments and Versioning.

• The System Definition object type located under the Harmony OPC Server

Network object has been eliminated. It has been replaced with a new INFI 90

System Definition object in the Library Structure and a new ServerConfig

aspect on the Harmony OPC Server Network object.

• Remote Motor Control Block (RMCB) Text configuration has been removed

from the Harmony Server TagConfig Aspect. RMCB Text configuration is now

provided by a new NLS Text Set on the new INFI 90 System Definition object

in the Library Structure.

• The Harmony Bulk Configuration Manager has been eliminated. The 800xA

Bulk Data Manager can now be used to make bulk changes to 800xA for

Symphony Plus Harmony TagConfig Aspects.

• The 800xA for Harmony Backup/Restore utility has been eliminated. 800xA

for Symphony Plus Harmony tag configuration data can now be backed up and

restored through the standard 800xA Aspect Directory backup/restore.

• The Harmony Server Monitor object and TagMonitor Aspects are no longer

needed and have been eliminated.

Moving a Tag Between Connectivity Servers

1. Navigate to the Harmony Tag to be moved in the Harmony Control Structure  hierarchy.

2. Right-click on the Object and then select Cut.

3. Navigate to the Loop, Node, Module location under the Harmony OPC Server  Network Object for the destination Harmony Server tag object.

The Loop,  Node and the Module Objects will need to be created, if they do not exist.

4. Right-click on the Module object and then select Paste.

5. If Enable On-line Change Notifications is disabled for the Harmony OPC  Server Network Objects,

hen the Harmony Servers will need to be restarted to  reflect the changes.

800xA for Symphony Plus Harmony communicates with the control systems  through a Cnet-to-computer interface (IET800, PNI800).

800xA for Symphony Plus Harmony is a distributed process management and  control system.

Using a series of integrated Harmony control units, the system  allows monitoring and control of process variables such as flow rate,

temperature,  and pressure according to a control configuration that the engineer or technician  defines.

A Harmony control unit is a controller and its I/O devices connected for  communication on control network (Cnet).

800xA for Symphony Plus Harmony operates in a Windows environment on  personal computer hardware.

Using interactive process graphics, the operator can  monitor and control all Analog loops and Digital devices interfaced to the network  through Harmony control units.

800xA for Symphony Plus Harmony provides maintenance personnel with the  capability to globally monitor

the operating status of any system component on the  network, and to diagnose component failures from any workstation.

800xA for Symphony Plus Harmony also provides the Harmony Executive Service.

It is an 800xA service that controls underlying 800xA for Symphony Plus Harmony  services.

processor load

• Optical communication

• Industrial grade hardware with no moving parts

• Long life cycle, easy upgrading

• Robust reliance file system, insusceptible post power loss

07EA90-SI ABB modules are used to convert analog signals to digital signals and transmit them to the control system for monitoring and controlling industrial processes.
