Emerson Ovation 5A26431G05 SUN ULTRA 10 Workstation Kit

The Ovation I/O modules are locked into base units. These base units are housed in

the Controller cabinets where they are mounted on DIN rails and wired to the

appropriate field devices.

The standard modular components typically consist of the following:

• Electronics module

• Personality module

• Base Unit (containing the field terminations)

The relay output modular components consist of the following:

• Electronics module

• Base Unit (containing the field terminations)

This manual describes the I/O modules and their usage in the Ovation system.

Clear, Concise Operations

Providing plant operators with a clear, concise, easy to navigate window to the process is vital to successful operations.

The Ovation Operator Workstation accomplishes that mission with crisp, high-resolution process graphics,

built-in trending data, advanced system diagnostics displays, user-friendly help screens and a sophisticated alarm management and analysis package

that prioritizes alarms to quickly isolate and address problems.

Ovation includes embedded applications such as fully coordinated boiler/turbine control,

emissions monitoring, economic dispatch and fleet management for power projects. For water,

wastewater, and renewable applications, Ovation incorporates a SCADA interface for wide-area monitoring and control,

seamless PLC integration, and comprehensive diagnostics programs.

Coupled with Emerson’s PlantWeb™digital architecture,

the Ovation system provides powerful technology for secure operations and best-in-class performance.

I/O Reference Manual Overview

The Ovation Distributed Control System provides modulating control, sequential

control, and data acquisition for a variety of system applications. This system

consists of a configurable mix of functional Input/Output (I/O) modules that

communicate on the I/O bus to the Ovation Controller.

I/O modules provide an interface between the Ovation Controller and the processes

in the plant. Ovation I/O modules are “plug-in” components with built-in fault

tolerance and diagnostics. They are able to operate on a wide range of signals and

perform a multitude of functions.

Tighter, More ReliableControl

The Ovation system is renowned for delivering precision control with outstanding performance.

That precision begins with the Ovation Controller. With an Intel-based

processor at its heart, the Ovation Controller provides full-redundancy to assure the reliability

and security necessary for even the most demanding application.

In addition to a comprehensive set of over 100 standard algorithms,

Ovation also provides the ability to embed advanced control algorithms that leverage the ever expanding

computing power of the Ovation Controller.

This capability allows you to take control to a higher level by incorporating model predictive control and

industry specific advanced applications to reduce process variability and optimize performance over the full range of plant operating conditions.

Recommended Products P/N：

Analog Input 20mV w/temp. sensor) (13 bit)1C31113G01 1C31116G04

Analog Input (50mV) (13 bit) 1C31113G02 1C31116G01

Analog Input (50mV w/temp. sensor) (13 bit) 1C31113G02 1C31116G04

Analog Input (1 VDC) (13 bit) 1C31113G04 1C31116G01

Analog Input (1mA, (using 250mV)   5X00070G02 1C31116G03

Analog Input (1mA, (using 250mV)  5X00070G02 1C31116G02

Analog Input (20mV, 50mV, 100mV) 5X00070G04 1C31116G01

Analog Input (20mV, 50mV, 100mV) 5X00070G04 1C31116G04

Analog Output (0 to +10 V) 4 1C31129G02 1C31132G01

Analog Output (0 to +5 V) 4 1C31129G01 1C31132G01

Analog Output (0-20 or 4-20 mAw/diagnostics) 1C31129G03 1C31132G01

Analog Output (0-20 or 4-20 mAw/o diagnostics)1C31129G04 1C31132G01

Contact Input w/Onboard 48 V wetting Compact) 1C31234G01

Analog Input (10 VDC) (13 bit) 1C31113G06 1C31116G01

Analog Input (5 VDC) (13 bit) 1C31113G05 1C31116G01

Analog Input (0-20 or 4-20 mA Local PS) 1C31113G05 1C31116G03

Analog Input (0-20 or 4-20 mA Remote PS)1C31113G05 1C31116G02

Analog Input (4-20 mA) (14 bit Low Speed) 1C31224G01 1C31227G01

Analog Input (1 VDC) (14 bit Low Speed) 1C31224G02 1C31227G02

Analog Input (4-20 mA) (14 bit High Speed 5X00070G01 1C31227G01

Analog Input (100mV, 250mV, 1V)5X00070G02 1C31227G02

Analog Input (5V, 10V) (14 bit HS) 5X00070G03 1C31227G02
