Woodward 8440-2052 easYgen-3200-5/P2 Genset Controller

Woodward 8440-2052: easYgen-3200-5/P2 Genset Controller

The Woodward 8440-2052 is a high-performance, versatile generator set controller belonging to the easYgen-3000 series (specifically the easYgen-3200-P2 model).

1 It is designed to manage complex power generation systems, providing comprehensive control, protection, and peer-to-peer paralleling for up to 32 generator sets.2

+1

As a "Package 2" (P2) model, it includes an integrated HMI with a color display and three additional freely configurable PID controllers for advanced process automation.3

Technical Parameter Table

Product Advantages and Features

Integrated LogicsManager™: Built-in programmable logic allows users to create custom control sequences, often eliminating the need for an external PLC.4

Advanced Paralleling: Supports load sharing and synchronization for up to 32 units in island mode or parallel with a utility grid.5

True RMS Sensing: High-precision voltage and current monitoring (Class 1 accuracy) ensures stability even in systems with high harmonic distortion.6

FlexIn™ Technology: Analog inputs are highly flexible, supporting various resistance sensors and mA signals without extra hardware.

Multi-Lingual HMI: The operator interface supports 14 standard languages, making it ideal for global deployments.7

Robust Protection: Includes over/under voltage, frequency, and speed protection, as well as unbalanced load and phase rotation monitoring.8

Application Cases

The 8440-2052 is the "brain" for critical power infrastructure:

Data Centers & Hospitals: Managing emergency standby power with Automatic Mains Failure (AMF) detection and fast-start synchronization.9

Island Prime Power: Used in remote villages, oil and gas platforms, and mines to manage multiple gensets sharing a local grid.10

Cogeneration (CHP): Utilizing the three P2-specific PID controllers to manage heat recovery processes alongside electrical power production.

Microgrids: Integrating renewable energy sources with traditional diesel or gas generators for stable power distribution.11

Related Models & Series

The easYgen-3000 family consists of several variations based on mounting and feature sets:

Other Models in the Series

8440-2050 (easYgen-3200-5/P1): The "Package 1" version (standard features, no extra PID controllers).12

8440-2051 (easYgen-3100-5/P1): Back-panel mount version (no display/buttons on the unit).

8440-2082 (easYgen-3200XT): The newer XT series with enhanced processing and Ethernet communication.13

8446-1048 (RP-3000): Remote operator panel used to control easYgen units from a distance.14

Related Accessories

LS-5 Series: Circuit breaker controllers used for complex bus-tie management in multi-breaker systems.

ToolKit Service Tool: Woodward's software used for configuration and real-time monitoring of the 8440-2052 via PC.15
