ProSoft MVI56E-MCMR Modbus Communication Module

The MVI56E-SIE Siemens Industrial Ethernet Communication Module allows Rockwell Automation ControlLogix

The Siemens Industrial Ethernet Communication Module allows Rockwell Automation ControlLogix Programmable Automation Controllers (PACs) to easily connect as Ethernet clients to up to 20 Siemens S7-200. S7-300. S7-400. S7-1200. and S7-1500 PLCs operating as Ethernet servers.

The module uses the ProSoft Configuration Builder (PCB), which provides graphical configuration tools

for managing module configuration files, as well as using the high-speed Ethernet port to view communications and module diagnostic information.

With ladder logic enable/disable commands, a variety of Siemens S7 CPUs can support a wide range of applications without having to reconfigure the module.

Data transfer with ControlLogix ® PAC uses scheduled I/O data for faster updates and better performance.

General Specifications

 Single-slot 1756 ControlLogix backplane compatible

 10/100 Mbps auto cross-detect Ethernet configuration and application port

 User-definable module data memory map of up to 5000 16-bit registers

 Enables CIPconnect network configuration and diagnostic monitoring using ControlLogix 1756-ENxT and 1756-CNB modules and EtherNet/IP passthrough communication

 Additional instructions (AOIs) for data transfer between modules and processors

 4-digit alphanumeric scrolling LED displays status and diagnostic data

 ProSoft Discovery Service (PDS) software for locating modules on the network and assigning temporary IP addresses

 Personalization Module - non-volatile, industrial-grade CF card for storing network and module configurations, allowing for quick product changes in the field by transferring CF cards
