schneiderModbus Master (Serial and TCP/IP) Driver for Field Device System Integrator Modules

technology. Using an Ethernet network, you can

provide remote access to process data over the

network.

Redundancy

A pair of FBM231 or 233 modules combine to

provide redundancy at the FBM level. In redundant

configurations, one FBM serves as the Master

module and the other as the Tracker module. (Both

are Modbus Masters on their respective networks.)

A communication link between the two modules

allows each module to monitor the other's health and

to share information about the health of the attached

slave devices. For illustrations of typical

configurations in which redundant FDSI FBMs

communicate with serial and Ethernet Modbus

devices, refer to PSS 21H-2Z31 B4 and

PSS 21H-2Z32 B4.

Detection of communication issues between the

FBM and the field are determined by the device

heartbeat or scan message.

If a message is missed, up to two retries are

performed. If the retries fail, the device is marked as

failed in System Monitor displays.

If a device failure is detected, the Master requests an

automatic role switch and generates a system alarm.

Role-switching occurs without a loss of data.

Alternatively, you can initiate a role switch between

Master and Tracker modules manually using

I/A Series System Monitor.

If any one FBM fails, the failure is indicated in System

Monitor. If a role switch has occurred and you are

running with a failed FBM, the new Master will

continue to detect and alarm device failures.

When the System Monitor alerts you to FBM or

network connection failures, you can then replace the

faulty FBM or repair the network connection without

upsetting field input or output signals on the

functional side. When a failure occurs, it is

recommended that you repair or replace the faulty

component as soon as possible to prevent possible

loss of data if another failure should occur.

Custom Drivers

Device-specific drivers can be created for unique

process requirements. For example, a custom driver

can be created to support Modbus slave devices, to

perform non-standard data type conversions in

systems that utilize a combination of data types, or to

support non-standard Modbus protocol

implementations. Contact your local Invensys

Foxboro sales representative for information on

specific custom drivers that may be available for your

system.

Diagnostics

System Monitor watches for loss of communication

between the Modbus field devices and the FDSI

FBM. FBMs scan their connected devices at a userspecified time interval. If the FBM does not receive a

response from the device, System Monitor displays

show that the device has failed.

The driver can be configured to send heartbeat poll

messages to devices that support function code 8.

This enables you to monitor device connection.

OVERVIEW OF MODBUS TECHNOLOGY

The Modbus Protocol was introduced by GouldModicon® in 1979 as a proprietary message

structure and format that allowed communication

and transfer of control data between intelligent field

devices via RS-232. Modbus/TCP was introduced

later by Schneider Automation® to support Ethernet

TCP/IP as an additional data transmission

technology for the Modbus protocol.

Today, Modbus has evolved into a globally accepted

and widely used standard for communication

between multi-vendor field devices. The Modbus

protocol specifies the master-slave/query-response

message structure that controllers can recognize and

use.

Messaging Operation

Query messages, sent by Modbus masters to

devices, include a destination address, a task

request indicated by a “function code”, and any

supporting data required for the slave to carry out the

assigned task. The message can be sent directly to a

particular slave by including its unique address in the

message.

After receiving a query message from the master, the

Modbus device responds with a message. The

response message specifies whether or not the

requested action was successfully performed and

confirms that the correct Modbus device responded

to the requested action. The response message also

returns any data requested by the master.

Query and response messages both contain error

checking mechanisms that allow devices to confirm

the integrity of the query message and allow the

master to confirm the integrity of the response. If the

error check is not correct, the associated query or

response message is ignored and the transaction is

retried.

Modbus Master Device Driver Operation

Modbus “function codes” specify the types of actions

the Modbus devices must perform. The following

Modbus function codes are supported by the FDSI

Modbus Master Driver:

* Data diagnostic code only.

You do not need to specifically configure Modbus

transactions, which makes driver configuration very

easy. By defining the necessary device register
