GE IC695CRU320 PACSystems RX3i Central Processing Unit Module

CPU

Product Overview

The GE IC695CRU320 is a high-performance Central Processing Unit (CPU) module designed for the PACSystems RX3i series. This advanced controller combines robust processing capabilities with exceptional reliability, making it an ideal choice for demanding industrial automation applications.

Key Innovation: The IC695CRU320 features advanced multi-tasking capabilities with real-time performance optimization, ensuring precise control in time-critical applications.

Technical Specifications

Parameter	Specification
Processor Type	32-bit ARM Cortex-A9
Clock Speed	1.0 GHz
Memory (RAM)	128 MB
Flash Memory	64 MB
Ethernet Ports	2 x 10/100 Mbps
Serial Ports	2 x RS-232/485
Operating Temperature	0°C to 60°C
Power Consumption	12W typical

Industry Applications

🏭

Manufacturing

Process control and automation in manufacturing facilities

⚡

Power Generation

Control systems for power plants and distribution networks

💧

Water Treatment

Monitoring and control of water treatment processes

🛢️

Oil & Gas

Pipeline monitoring and refinery process control

🚇

Transportation

Railway signaling and traffic management systems

🏢

Building Automation

HVAC control and energy management systems

Key Features & Benefits

High-Speed Processing

1.0 GHz ARM Cortex-A9 processor delivers exceptional computational performance for complex control algorithms and real-time operations.

Dual Ethernet Connectivity

Two independent Ethernet ports enable redundant network connections and advanced networking topologies for improved system reliability.

Flexible Communication

Multiple serial ports support various industrial protocols including Modbus, DNP3, and proprietary communication standards.

Robust Memory Architecture

128 MB RAM and 64 MB Flash memory provide ample space for complex applications and data logging requirements.

Industrial-Grade Reliability

Designed to operate in harsh industrial environments with extended temperature ranges and enhanced EMI protection.

Scalable Platform

Compatible with the complete PACSystems RX3i ecosystem, allowing for easy system expansion and integration.

Related Models Comparison

IC695CRU320

Current Model

1.0 GHz ARM Cortex-A9

128 MB RAM

2x Ethernet

IC695CPE310

Entry Level

400 MHz ARM9

64 MB RAM

1x Ethernet

IC695CPE330

Mid Range

800 MHz ARM Cortex-A8

128 MB RAM

2x Ethernet

IC695CPE400

High Performance

1.2 GHz ARM Cortex-A9

256 MB RAM

3x Ethernet

Programming & Configuration

Software Environment

The IC695CRU320 is programmed using GE's Machine Edition software, which provides a comprehensive development environment supporting multiple IEC 61131-3 programming languages:

Ladder Diagram (LD)

Traditional relay logic programming for electrical engineers and maintenance personnel.

Function Block Diagram (FBD)

Graphical programming approach ideal for process control applications.

Structured Text (ST)

High-level programming language for complex mathematical operations and algorithms.

Sequential Function Chart (SFC)

Step-based programming for batch processes and sequential operations.

System Integration

The IC695CRU320 seamlessly integrates with various industrial protocols and systems, including EtherNet/IP, Modbus TCP/IP, PROFINET, and OPC-UA, ensuring compatibility with existing infrastructure and third-party devices.

Installation & Maintenance

Physical Installation

The module features a compact form factor designed for standard DIN rail mounting in industrial control panels. The unit includes:

Hot-swappable design for minimal downtime during maintenance
LED status indicators for quick system diagnostics
Removable terminal blocks for easy wiring and replacement
Built-in surge protection for enhanced reliability

Maintenance Features

Advanced diagnostic capabilities include real-time monitoring of system performance, automatic error logging, and predictive maintenance alerts to ensure optimal system operation and minimize unplanned downtime.
