schneiderFoxboro Evo™ Process Automation System Product Specifications

The Field Control Processor 280 is a distributed, optionally fault-tolerant, field-mounted controller that

performs process control and alarming functions according to a user-defined control strategy.

FEATURES

 Performs regulatory, logic, timing, and sequential

control together with connected Fieldbus

Modules (FBMs)

 Performs data acquisition and alarm detection

and notification

 Supports up to 128 Compact or standard

200 Series FBMs, or up to 128 of a combination

of 100 Series FBMs and 200 Series FBMs (with

no more than 64 100 Series FBMs in this

configuration)

No Fieldbus Communication Module is required.

 No Fieldbus Expansion Module is required for

Expanded fieldbus support.

 Supports self-hosting mode, which allows the

FCP280 to boot itself with a valid control

database even without its host workstation

 Offers unique, patented, fault-tolerant operation

using two control modules to greatly improve

reliability relative to other process controllers

 Offers on-line image upgrade (OLUG) of a faulttolerant FCP280 without shutting down the

process

 Liquid Crystal Display (LCD) displays letterbug

and real-time roles and statuses

 Connects to The Mesh control network via

standard fiber optic or copper 100 Mbps

Ethernet cables

 Uses a rugged, die cast aluminum housing for

mounting in a non-vented field enclosure

 Can operate in Class G3 harsh environments

 CE certified for field mounting in enclosures

 Each Fieldbus port on FCP280 baseplates

supports either a 2 Mbps or 268 Kbps HDLC

fieldbus exclusively

 Uses versatile control algorithms and a wide

variety of FBMs to provide control capabilities for

a broad range of process applications

 Supports time synchronization using optional

external time from GPS satellites

 Uses soft letterbugs configurable via the keys on

the FCP280 faceplate.

OVERVIEW

The Field Control Processor 280 (FCP280) is a

distributed, optionally fault-tolerant, field-mounted

controller module. The FCP280 performs regulatory,

logic, timing, and sequential control together with

connected Fieldbus Modules. It also performs data

acquisition and alarm detection and notification.

The FCP280 connects to The Mesh control network

via standard fiber optic or copper 100 Mbps Ethernet

cables from network adapters installed on its

baseplate (shown in Figure 1).

The FCP280 requires Foxboro Evo Control Core

Services v9.0 or later. A system with the FCP280 and

this software is called a Foxboro Evo Process

Automation System

Figure 1. Fault-Tolerant FCP280 Module Pair Mounted on Vertical Mounted 2-Position FCP280 Baseplate

The fault-tolerant version of the FCP280 consists of

two processor modules. These modules are installed

in adjacent FCP280 slots in a baseplate for high

speed communication between the modules.

The FCP280 accepts four PIO channels (that is, four

separate HDLC fieldbuses) via the four Fieldbus ports

on its baseplate. These four Fieldbuses are referred

to collectively as the “Expanded fieldbus.” For a

description of the FCP280 baseplates, refer to DIN

Rail Mounted Modular Baseplates

(PSS 21H-2W6 B4).

The number of FBMs which an FCP280 can support

varies depending on the types of FBMs used:

 200 Series FBMs exclusively used with FCP280 -

Each Fieldbus port on the FCP280 baseplate can

connect to a baseplate chain with up to 32

Compact or standard 200 Series FBMs per chain

via the 2 Mbps HDLC fieldbus (up to 128

modules).

 200 Series and 100 Series FBMs (dual baud

configurations) used with FCP280 - The FCP280

can support a total of 64 100 Series FBMs (Ymodule) or competitive devices (such as Foxboro

Evo System migration FBMs) in one or more

baseplate chains, with the remainder of the

FCP280’s 128 module limit being 200 Series

FBMs, depending on the Fieldbus loading of the

FCP280. For example, an FCP280 could support

64 100 Series FBMs and 64 200 Series FBMs (as

128 - 64 = 64). See Figure 2 and Figure 3 below.

NOTE

Certain competitive migration or supported

third-party modules such as DCS Migration

fieldbus Modules and Pepperl+Fuchs™ I/O

modules may increase this 128 module

maximum per FCP280. For the maximum

numbers of each of these migration/thirdparty modules supported by the FCP280,

refer to the supported migration products

books in Field Control Processor 280

(FCP280) User’s Guide (B0700FW).

When supporting 200 Series and 100 Series FBMs,

each Fieldbus port (PIO channel) is dedicated to

supporting either a 268 Kbps HDLC fieldbus (for

100 Series FBMs) or a 2 Mbps HDLC fieldbus (for

200 Series FBMs) - not both.

For connections to 100 Series FBMs over 60 m

(198 ft), an FBI200 pair is required to extend

communications up to 1830 m (6000 ft). See

Figure 2 below.

To connect a Fieldbus port to a 268 Kbps HDLC

fieldbus directly, the Fieldbus splitter (RH928CV)
