A-BControlLogix 32-point DC (10…31.2V) Input Module, Series B

European Hazardous Location Approval

Consider the following if you install the module in a European Zone 2

location.

European Zone 2 Certification (The following applies when the product bears the

Ex or EEx marking.)

This equipment is intended for use in potentially explosive atmospheres as defined by

European Union Directive 94/9/EC and has been found to comply with the Essential Health

and Safety Requirements relating to the design and construction of Category 3 equipment

intended for use in potentially explosive atmospheres, given in Annex II to this Directive.

Compliance with the Essential Health and Safety REquirements has been assured by

compliance with EN 60079-15 and EN 60079-0.

WARNING • This equipment must be installed in an enclosure providing at least

IP54 protection when applied in Zone 2 environments.

• This equipment shall be used within its specified ratings defined

by Allen-Bradley.

• Provision shall be made to prevent the rated voltage from being

exceeded by transient disturbances of more than 40% when

applied in Zone 2 environments.

• This equipment must be used only with ATEX certified backplanes.

• Secure any external connections that mate to this equipment by

using screws, sliding latches, threaded connectors, or other means

provided with this product.

• Do not disconnect equipment unless power has been removed or

the area is known to be nonhazardous.

ATTENTION This equipment is not resistant to sunlight or other sources of UV

radiation.

North American Hazardous Location Approval

The following information applies when

operating this equipment in hazardous

locations:

Informations sur l’utilisation de cet

équipement en environnements dangereux:

Products marked ‘CL I, DIV 2, GP A, B, C, D’ are

suitable for use in Class I Division 2 Groups A, B,

C, D, Hazardous Locations and nonhazardous

locations only. Each product is supplied with

markings on the rating nameplate indicating the

hazardous location temperature code. When

combining products within a system, the most

adverse temperature code (lowest ‘T’ number)

may be used to help determine the overall

temperature code of the system. Combinations of

equipment in your system are subject to

investigation by the local Authority Having

Jurisdiction at the time of installation.

Les produits marqués ‘CL I, DIV 2, GP A, B, C, D’ ne

conviennent qu'à une utilisation en environnements

de Classe I Division 2 Groupes A, B, C, D dangereux

et non dangereux. Chaque produit est livré avec des

marquages sur sa plaque d'identification qui

indiquent le code de température pour les

environnements dangereux. Lorsque plusieurs

produits sont combinés dans un système, le code de

température le plus défavorable (code de

température le plus faible) peut être utilisé pour

déterminer le code de température global du

système. Les combinaisons d'équipements dans le

système sont sujettes à inspection par les autorités

locales qualifiées au moment de l'installation.

WARNING EXPLOSION HAZARD -

•Do not disconnect equipment

unless power has been removed or

the area is known to be

nonhazardous.

•Do not disconnect connections to

this equipment unless power has

been removed or the area is known

to be nonhazardous. Secure any

external connections that mate to

this equipment by using screws,

sliding latches, threaded

connectors, or other means

provided with this product.

•Substitution of components may

impair suitability for Class I,

Division 2.

•If this product contains batteries,

they must only be changed in an

area known to be nonhazardous.

AVERTISSEMENT RISQUE D’EXPLOSION –

•Couper le courant ou s'assurer

que l'environnement est classé

non dangereux avant de

débrancher l'équipement.

•Couper le courant ou s'assurer

que l'environnement est classé

non dangereux avant de

débrancher les connecteurs.

Fixer tous les connecteurs

externes reliés à cet équipement

à l'aide de vis, loquets

coulissants, connecteurs filetés

ou autres moyens fournis avec

ce produit.

•La substitution de composants

peut rendre cet équipement

inadapté à une utilisation en

environnement de Classe I,

Division 2.

•S'assurer que l'environnement

est classé non dangereux avant

de changer les piles.

About the Module

ControlLogix I/O modules mount in a ControlLogix chassis and require

either a removable terminal block (RTB) or a 1492 interface module (IFM)(1)

to connect all field-side wiring.

Before You Begin

Before you install your I/O module, you should:

• identify the module components.

• note the power requirements.

Module Components

You received these components with your order:

• 1756-IB32 module

• Removable terminal block (RTB) door label

If you did not receive these components, contact your local distributor or

Rockwell Automation sales office.
