ABB 2VAA008419R11 cHBS01-CJCA Horiz Base Single Compact

Features and benefits

Termination for up to eight (8) analog I/O process signals within a horizontal row.

All SD I/O modules & bases of all types (Singular or Redundant) AND (Compact or Full-size), are

100% fully compatible with each other. Thus, Singular & Redundant, Compact or Full-size I/O

modules can be mounted within a single, common HN800 I/O bus.

Optional mechanical keying can be implemented to prevent insertion of the wrong I/O module

type.

Latching device on the base locks the base into position on DIN-Rail.

Industry standard 35-mm DIN rail, Horizontal row mounting.

Time Synchronization

Enable Time Synchronization

Determines whether or not the Server receives and sends the time synchronization

on the network. When enabled, the Server is in time synchronization with the

control network.

Accuracy

Time synchronization accuracy of the Server is valid when the Server is in time

synchronization mode. The options are:

• Low accuracy (lowest accuracy); priority 0.

• Low accuracy battery backed; priority 3.

• High accuracy battery backed; priority 6.

• IIOIS20 node; priority 9.

• IIOIS20 SCSI; priority 10.

• PIMS SCSI; priority 11.

• Satellite clock system (highest accuracy); priority 12.

These accuracy settings are only used when negotiating for time mastership with

other nodes in the underlying Harmony control network.

Master Update Period

Master update period is the frequency that Harmony Server synchronizes time with

the underlying Harmony control network. This property is used only when Time

Synchronization is enabled. The permissible values are 120 to 3540 seconds.

Message Wait Period

Message wait period is the Period that Harmony Server waits before attempting to

assume time mastership on the control network. This property is used only when

Time Synchronization is enabled. The permissible values are between 180 and 3660

seconds. Additionally, the configured value must greater than the Master Update

Period.

Sending Global Alarm Acknowledgement Messages to the Loop

Enable Tag Acknowledgment Broadcast

To broadcast an alarm acknowledgement for a specific Harmony tag:

– Select the Tag Acknowledgment Broadcast Enable check box on the  Harmony Tab of the tag. Selecting the

checkbox enables the connectivity server to broadcast the alarm  acknowledgement for this tag on the communication highway.

Enable Acknowledgment Transmission

Configure the module status tag for each node to which the connectivity server  transmits the alarm acknowledgment messages.

For each module status tag, on the  Module tab, select the Enable Alarm Acknowledgment

Transmission check box to  have the connectivity server transmit any recently acknowledged alarms.

Broadcasts  will only be sent to a node when the corresponding module status tag is configured  and has alarm acknowledgment transmission enabled.

Receiving Global Alarm Acknowledgement from the Loop

Configure the Harmony Server tag to enable receiving global alarm  acknowledgment messages from other nodes on the loop.

On the Harmony tab, select the Global Alarm Acknowledgement check box to

enable the connectivity server to process the Global Alarm Acknowledgement  messages received through the INFI-NET loop.

The connectivity server applies the alarm acknowledgement to the harmony tag that  has the same Harmony address as the broadcast tag.
