EMERSON DeltaV KJ1501X1-BC1 System Dual DC Power Supply (DC/DC)

Quickly tune loops for improved control. Properly tuned loops can decrease process variability and increase profits through improved

product quality, throughput, and equipment availability. DeltaV InSight continuously monitors control performance and provides

adaptive tuning recommendations for every PID loop in the system based on normal day-to-day operations. No disruptive plant tests are

required. You may also initiate on-demand tuning to automatically step the process and calculate tuning for PID and Fuzzy logic control

loops.

Test tuning with simulation. For the advanced user,DeltaV InSight provides sophisticated but easy-to-use loop simulation and analysis

tools. This allows predicted control loop performance to be analyzed before the new tuning parameters are updated in the controller.

Generate reports to track control performance.

DeltaV InSight Performance Reports provide operations,maintenance and control personnel the ability to easily track key control

performance indicators; from a single loop to an entire plant area. Standard reports are included with Insight,with the ability to create

custom reports to include KPI’s specific to your facility. All reports may be created on-demand or generated automatically for periodic

distribution.

Easy to Use. As an embedded application in the DeltaV system, InSight requires no software installation, integration,or configuration.

Using DeltaV software’s common configuration database, InSight automatically recognizes input, output and control blocks as they are

added to or deleted from the system. This means faster startups and less maintenance.

Two separate output schemes are available:

▪ 24 VDC / 10 A / 240 W main and 24 VDC / 10 A / 240 W auxiliary power

▪ 24 VDC / 20 A / 480 W main and 24 VDC / 20 A / 480 W auxiliary power

Benefits of the Ovation power supply scheme include:

▪ Separate main and auxiliary power supplies allow easy replacement

▪ Elimination of cooling fans greatly reduces failure risks

▪ Diode auctioneered power feeds assure continuous power availability

▪ New design increases efficiency, reduces heat generation and enhances equipment life expectancy

▪ Dual input (AC and DC) capability reduces spare parts

▪ Hot-swappable power supplies enable on-line replacement

 ▪ Quick installation of the power supplies minimizes downtime and production loss ▪ Power factor correction reduces power consumption

▪ Redundant power configurations, each with separate external wide-range AC or DC feeds

▪ Separate main and auxiliary supplies in both the primary and secondary configurations

▪ Dual wide-range input capabilities

▪ Diode auctioneered power feeds

 ▪ High-efficiency power supplies

 ▪ Modular fanless systems

▪ Redundant power feeds to each controller chassis and to the I/O modules

▪ Continuous system monitoring

DeltaV InSight also performs better because the control calculations are embedded directly in the controller.

Calculations for control performance, diagnostics, and tuning require a lot of information,which can significantly add to system communications loading.

Embedded calculations greatly reduce the system communications as compared with traditional OPC data access.

Furthermore, for fast loops, it’s virtually impossible to scan the control loop via OPC fast enough for accurate calculations.
