IS420ESWAH3A

Part Number IS420ESWAH3A Manufacturer General Electric Country of Manufacture As Per GE Manufacturing Policy Series Mark VI/VIe Function Module Availability In StockIS420ESWAH3A is an IONet Ethernet Switch developed by GE and is part of the General Electric Speedtronic Mark VIe gas turbine control systems. It uses Achilles-certified controllers and current Fieldbus technology to meet NERC version 5 Protection Reliability Standards for Critical Infrastructure. The component has eight ports with 10/100BASE-TX capability. It's one of numerous Ethernet switch models available for use with the Mark VIe system. It features a conformal coating and is suitable for usage in hazardous environments. The machine can function in temperatures ranging from -40 to 158 degrees Fahrenheit. IS420ESWAH3A Features Compatibility with 802.3, 802.3u, and 802.3x 10/100 base copper with auto-negotiation Full/half duplex auto-negotiation 100 Mbps FX uplink port HP-MDIX auto-sensing Link Presence, Activity, Duplex, and Speed per port LEDs (each LED has two colors) Power LED 256 KB buffer with 4K media access control (MAC) addresses Flow Control Flow control between switches is supported by the switch. It receives and honors pause packets using IEEE defined pause packets. The switch only sends pause packets if a port requires flow control. IONet Ethernet Switch Reliability and Performance Because high reliability is critical in the controls solutions industry, the switch has a Mean Time Between Failure (MTBF) of more than 4 million hours at 35脗掳C (95 脗掳F) ambient temperature, ground fixed controlled environment. Product Attributes Mounting The switch enclosure can be panel mounted (the switch is bracket mounted to the back wall of the panel) or DIN-rail mounted. DIN-rail mounting satisfies vibration and shock requirements. Both mounting types allow for easy access to user connections. Dimensions 138 x 86 x 56 mm (5.45 x 3.40 x 2.20 in) Power Connection Supports two redundant diode-OR芒聙聶d power supply inputs of 18 to 36 V dc Cooling Convection cooled when mounted vertically or horizontally Coating Resistant to corrosion with provisions made for grounding per IEC 60721-3-3 Class 3C2 Operating temperature -30 to 65脗掳C (-22 to 149 脗掳F) Shipping, storage temperature -40 to 85脗掳C (-40 to 185 脗掳F) Humidity Operates in a 5 to 95% relative humidity, non-condensing environment without any external temperature or humidity excursions Seismic Vibration Meets Universal Building Code (UBC) Diagnostics Link presence, activity and duplex, and port speed LEDs have two colors that indicate their status. LED One Full Duplex activity is indicated by a green flash. Yellow flashes for activity at Half Duplex LED Two Green indicates a link and 100 Mb. Yellow indicates a link and 10 Mb. No link = no led lit IS420ESWAH3A Benefits Longer availability of parts for future network expansion Backward compatibility with legacy systems Improved performance for real-time control systems IS420ESWAH3A Conformance Criteria IEEE 1588 timing can be used to synchronize packet traffic and trigger it to begin within a 1-microsecond packet start window. The following four criteria are used to assess capability and conformance: Starting the required Multicast packet load on a single port without negotiating IEEE 802.3x flow control Begin the required Multicast packet load on a single port, with IEEE 802.3x flow control negotiated Initiation of the required Multicast packet load distributed across all ports, with no IEEE 802.3x flow control. Start the required packet Multicast load across all ports; packet count per port must average 200 per number of switch ports, with IEEE 802.3x flow control negotiated on half of the ports.MK6e IONet SWITCH, 8PORT 10/100 Cu
