HIMA F7105A PLC Module
❤ Add to collection

HIMA F7105A PLC Module

 Overview

The HIMA F7105A is a high-performance programmable logic controller (PLC) module designed for safety-critical applications in industrial automation. Compliant with international safety standards such as IEC 61508 (SIL 3) and EN 50155, it ensures reliable operation in harsh industrial environments, including process control, machinery safety, and critical infrastructure systems.


￥0.00
￥888.00
￥888.00
￥888.00
Weight：11.000KG
Description

 Overview

The HIMA F7105A is a high-performance programmable logic controller (PLC) module designed for safety-critical applications in industrial automation. Compliant with international safety standards such as IEC 61508 (SIL 3) and EN 50155, it ensures reliable operation in harsh industrial environments, including process control, machinery safety, and critical infrastructure systems.


HIMA F7105A PLC Module User Manual

1. Overview

The HIMA F7105A is a high-performance programmable logic controller (PLC) module designed for safety-critical applications in industrial automation. Compliant with international safety standards such as IEC 61508 (SIL 3) and EN 50155, it ensures reliable operation in harsh industrial environments, including process control, machinery safety, and critical infrastructure systems.

2. Technical Specifications

ParameterSpecification
Power Supply24V DC ±15%, 1.2A maximum current consumption
Processor32-bit RISC processor with 800 MHz clock speed
Memory16 MB Flash memory, 8 MB RAM
I/O Interfaces8 digital inputs (24V DC), 8 digital outputs (24V DC, 2A per channel)
CommunicationEthernet (10/100 Mbps), PROFIBUS DP, RS485
Operating Temp-40°C to +70°C (-40°F to +158°F)
CertificationsIEC 61508 SIL 3, EN 50155, ATEX, UL 508

3. Installation

3.1 Mounting

  • Install the module on a DIN rail (35mm) in a control cabinet with proper ventilation.

  • Ensure a minimum clearance of 50mm between adjacent modules for heat dissipation.

3.2 Wiring

  • Connect the power supply to the terminal block marked "PWR IN" (L+: 24V DC, L-: 0V DC).

  • Wire digital inputs to terminals "DI 0-7" and outputs to "DO 0-7"; use twisted-pair cables for signal lines.

  • Connect communication interfaces (Ethernet, PROFIBUS) via their respective ports; secure cables with cable glands.

4. Configuration & Programming

4.1 Software Requirements

  • Use HIMA Planar 5 programming software (version 9.0 or higher) for configuration and logic development.

  • Install the latest device description files (GSD/GSDML) for integration into engineering tools.

4.2 Programming Steps

  1. Create a new project in Planar 5 and select the F7105A module from the device library.

  2. Define I/O mappings, communication parameters, and safety functions (e.g., emergency stop logic).

  3. Program safety-related logic using Safety Logic Diagram (SLD) or Structured Text (ST); ensure compliance with SIL 3 requirements.

  4. Compile the program, perform a syntax check, and download it to the module via Ethernet.

5. Operation & Monitoring

  • Power on the module; the "PWR" LED will illuminate green when the power supply is stable.

  • The "RUN" LED indicates normal operation (green); a red "FAULT" LED signals errors (check diagnostic logs via Planar 5).

  • Monitor real-time data (I/O status, communication traffic) using the software’s online monitoring function.

6. Maintenance & Troubleshooting

6.1 Routine Maintenance

  • Inspect wiring connections quarterly for tightness and corrosion.

  • Clean dust from ventilation slots annually to prevent overheating.

6.2 Common Issues

SymptomCauseSolution
"FAULT" LED onPower supply fluctuation or program errorCheck voltage; reload valid program
No communicationLoose Ethernet cable or incorrect IP setupReconnect cable; verify network settings
Outputs not respondingBlown fuse in DO circuitReplace fuse (2A per channel)

7. Safety Notes

  • Do not modify the module’s hardware or software without authorization; this may invalidate safety certifications.

  • Disconnect power before wiring or replacing the module to avoid electric shock.

  • Ensure all safety functions are validated by a qualified safety engineer before commissioning.
