ACS880-M04-010A-5+N5700

=The ACS880-M04-010A-5 + N5700 is a combination of an ABB ACS880-M04-010A-5 frequency converter and the N5700 component. Here is a detailed description of each part: ### ACS880-M04-010A-5 - **General Information**:    - **Product ID**: 3AXD50000036405.    - **Origin**: Manufactured in Finland.

- **Electrical Specifications**:    - **Input Voltage (U_in)**: 380 V - 500 V, three-phase.    - **Rated Current**: Normal use (I_n): 10.5 A; Light-overload use (I_ld): 9.7 A; Heavy-duty use (I_hd): 9 A.    - **Rated Power**: Normal use (P_n): 4 kW; Light-overload use (P_ld): 4 kW; Heavy-duty use (P_hd): 4 kW.    - **Apparent Power Output**: 7.3 kV·A.    - **Power Factor**: 0.98. - **Mechanical Specifications**:    - **Dimensions**: Net depth/length: 234 mm, net height: 476 mm, net width: 100 mm; Package level 1 depth/length: 450 mm, height: 360 mm, width: 200 mm.    - **Weight**: Product net weight is 5.6 kg.    - **Enclosure Type**: Open type with a degree of protection of IP20 and conforms to NEMA standards. - **Performance and Functionality**:    - **Control Technology**: Utilizes advanced control technology to precisely regulate the speed and torque of the connected motor, ensuring smooth and efficient operation in various industrial applications.    - **Energy Efficiency**: With an efficiency level of IE2, it helps optimize energy consumption during motor operation, contributing to cost savings and energy conservation in industrial processes.    - **Safety Features**: Incorporates safety functions such as Safe Torque Off (STO) to enhance the safety of personnel and equipment in the event of an emergency stop.    - **Diagnostic Capabilities**: Equipped with a comprehensive self-diagnostic system that continuously monitors the drive's performance and quickly alerts users to any potential faults or abnormal conditions, minimizing downtime and maintenance efforts. - **Interfaces and Communication**:    - **Digital I/O**: It has 6 digital inputs and 5 digital outputs, providing flexibility for connecting external control signals and enabling interlocking with other equipment.    - **Communication Protocols**: Supports multiple communication protocols including CAN, DeviceNet, Ethernet/IP, Modbus, Profisafe, Profibus, Profinet IO, and TCP/IP, facilitating seamless integration into industrial automation networks for remote monitoring and control.    - **Analog I/O**: Comes with 2 analog inputs and 2 analog outputs, allowing for connection with analog sensors and actuators for more precise control and monitoring of processes. ### N5700 - Regarding the N5700 component, without further specific details, it is difficult to provide an in-depth description. However, typically in such combinations, the N5700 could potentially be an additional module or accessory that complements the functionality of the ACS880-M04-010A-5 frequency converter. It might serve purposes such as enhancing communication capabilities, providing additional input/output options, or enabling specific application-specific functions. Overall, the ACS880-M04-010A-5 + N5700 combination offers a comprehensive solution for industrial motor control applications, providing reliable performance, energy efficiency, and advanced functionality to meet the demands of various industrial processes.
